644 Brocade Mobility RFS4000, RFS6000 and RFS7000 CLI Reference Guide
53-1001931-01
Wireless configuration commands
20
radio
Wireless configuration commands
Sets radio related parameters
Supported in the following platforms:
• Mobility RFS4000 Controller
• Mobility RFS6000 Controller
• Mobility RFS7000 Controller
NOTE
The radios group-id range differs from controller to controller.
- Mobility RFS7000 Controller – Supports a range between 0-255
- Mobility RFS6000 Controller – Supports a range between 0-64
- Mobility RFS4000 Controller – Supports a range between 1-6
Syntax
radio [<1-4096>
|
<radio-list>|add|all-11a|all-11an|all-11b|
all-11bg|all-11bgn|antenna-mode|configure-8021X|
default-11a|default-11an|default-11b|default-11bg|
default-11bgn|dns-name]
radio [<1-4096>|<radio-list>|all-11a|all-11an|all-llb|
all-11bg|all-11bgn|default-11a|default-11an|default-11b|
default-11bg||default-11bgn] [admission-control|
adoption-policy|adoption-pref-id|ampdu|amsdu|antenna-mode|
base-bridge|beacon-interval|bridge-fwd-delay <4-30>|
bridge-hello <1-10>|bridge-max-ageout <4-3600>|
bridge-msg-age <6-40>|bridge-priority <0-65535>|bss|
channel-power|client-bridge|copy-config-from|description|
detector|dtim-period|dot11k|enforce-spec-mgmt|
enhanced-beacon-table|enhanced-probe-table|
group-id [<0-48>|<0-255>|<0-64>]|location-led|
location-message|mac|max-clients|mesh-associations|
moto-simple-voice enable|mu-power <0-20>|nas-id|
nas-port-id|on-channel-scan|radio-number|
radar-test-mode|reset|reset-ap|
|rf-mode|rss|rts-threshold|run-acs|
self-heal-offset|short-gi|short-preamble|speed|timeout|
tunnel|wmm]
radio <1-4096>
admission control
voice [max-mu <1-256>|
max-perc <1-100>|max-roamed-mus <0-256>|
res-roam-perc <0-100>]
radio <1-4096> adoption-policy [allow|deny]
radio <1-4096> adoption-pref-id <0-65535>
radio <1-4096> ampdu [min-spacing|rx-limit|tx-enable|
tx-limit]
radio <1-4096
>
ampdu min-spacing [.25|.5|0|1|2|4|8]
radio <1-4096> ampdu rx-limit [16383|32767|65535|8191]
radio <1-4096> ampdu tx-enable
radio <1-4096> ampdu tx-limit <0-65535>
