Brocade Mobility 1220 Access Point Installation Guide 7
53-1002916-01
Chapter
2
Hardware Installation
Installation instructions
The Mobility 1220 Access Point mounts either on a wall (with customer supplied
M4 x 25 pan head screws and wall anchor - or equivalent) or on a suspended
ceiling T-bar. If deploying an external antenna model Mobility 1220 on a suspended
ceiling T-bar, access point mounting kit (Part No. KT-135628-01) is required. A
Mobility 1220 is not designed for mounting on a desk.
To prepare for the installation:
1. Match the model number on the purchase order with the model numbers in the
packing list and on the case of the access point.
2. Verify the contents of the box include the intended Mobility 1220 Access Point,
and the included hardware matches the package contents on page 5.
3. Review site survey and network analysis reports to determine the location and
mounting position for the Mobility 1220 Access Point.
Part Number Description
BR-AP122066030US Dual 802.11n radio Mobility 1220 Access Point. Plastic enclosure
with internal antennas. For use in the US deployments only.
BR-AP122066030EU Dual 802.11n radio Mobility 1220 Access Point. Plastic enclosure
with internal antennas. For use in European countries only.
BR-AP122066030WW Dual 802.11n radio Mobility 1220 Access Point. Plastic enclosure
with internal antennas. For use in non-US and non-EU countries only.
BR-AP122066040US Dual 802.11n radio Mobility 1220 Access Point. Metal enclosure with
external antenna connectors. For use in US deployments only.
BR-AP122066040EU Dual 802.11n radio Mobility 1220 Access Point. Metal enclosure with
external antenna connectors. For use in European countries only.
BR-AP122066040WW Dual 802.11n radio Mobility 1220 Access Point. Metal enclosure with
external antenna connectors. For use in non-US and non-EU countries
only.
