Integrated antenna model wall mount instructions
2
12 Brocade Mobility 1220 Access Point Installation Guide
53-1002916-01
4. If required, install and attach a Kensington security cable (customer supplied)
to the unit’s lock port.
5. Attach an Ethernet cable from the access point to a controller or Ethernet
switch with an 802.3af-compatible power source or use the
PWRS-14000-148R power supply to supply power to the Mobility 1220 Access
Point (once fully cabled).
6. Place the middle of each of the case’s mount slots over the screw heads.
7. Slide the case down along the mounting surface to hang the mount slots on the
screw heads.
8. Verify the unit has power by observing that the LEDs are lit or flashing.
CAUTION
If not using a 802.3af capable device to power the Mobility 1220
Access Point, ensure only the Mobility 1220 Access Point’s designated
power supply (PWRS-14000-148R) is used to supply power to the
access point. Using an incorrectly rated power supply could damage
the unit and void the product warranty. Do not actually connect to the
power source until the cabling portion of the installation is complete.
