Brocade Mobility 1220 Access Point Installation Guide 48
53-1002916-01
Chapter
4
Specifications
Mobility 1220 integrated antenna model electrical
characteristics
A Mobility 1220 integrated antenna Access Point has the following electrical
characteristics:
Mobility 1220 integrated antenna model physical
characteristics
A Mobility 1220 integrated antenna Access Point has the following physical
characteristics:
Operating Current &
Voltage
12VDC, 1A (accessory power connector)
48V,0.25A (PoE connector)
Dimensions
9.38 inches x 7.5 inches x 1.38 inches
23.82 cm x 19.50 cm x 3.50 cm
Housing
Plastic
Weight
0.90 lbs / 0.40 kg
Operating Temperature
32°F to 104°F/0°C to 40°C
Storage Temperature
-40°F to 185°F/-40°C to 85°C
Operating Humidity
5 to 95% Relative Humidity non-condensing
Storage Humidity
85% Relative Humidity non-condensing
Operating Altitude (max)
8,000 ft @ 28C
Storage Altitude (max)
30,000 ft @ 12C
Electrostatic Discharge
+/-15kV Air and +/-8kV Contact @ 50% Relative Humidity
