Mobility 1220 external antenna model electrical
characteristics
A Mobility 1220 external antenna Access Point has the following electrical
characteristics:
Mobility 1220 external antenna model physical
characteristics
A Mobility 1220 external antenna Access Point has the following physical
characteristics:
Operating Current &
Voltage
12VDC, 1A (accessory power connector)
48V,0.25A (PoE connector)
Dimensions
7.88 inches x 5.00 inches x 1.00 inches
20.01 cm x 12.70 cm x 2.54 cm
Housing
Metal
Weight
1.45 lbs / 0.65 kg
Operating Temperature
32°F to 104°F/0°C to 40°C
Storage Temperature
-40°F to 185°F/-40°C to 85°C
Operating Humidity
5 to 95% Relative Humidity non-condensing
Storage Humidity
85% Relative Humidity non-condensing
Operating Altitude
(max)
8,000 ft @ 28C
Storage Altitude
(max)
30,000 ft @ 12C
Electrostatic Discharge
+/-15kV Air and +/-8kV Contact @ 50% Relative Humidity
