Remote and Standalone Antenna Configurations
To comply with FCC RF exposure requirements, antennas that are mounted
externally at remote locations or operating near users at stand-alone desktop of
similar configurations must operate with a minimum separation distance of 20 cm
from all persons.
Power Supply
Use ONLY a LISTED Type no. PWRS-14000-148R (12VDC @ 4.16A), direct plug-in
power supply, marked Class 2 (IEC60950-1, SELV).
This device can be powered from a 802.3af compliant power source which is
certified by the appropriate agencies.
Use of alternative Power Supply will invalidate any approvals given to this unit and
may be dangerous.
Wireless Devices - Countries
Country Selection
Select only the country in which you are using the device. Any other selection will
make the operation of this device illegal.
NOTE
The US only models (BR-AP122066030US and BR-AP122066040US) have the
country code permanently set to the US. The EU only models (BR-AP122066030EU
and BR-AP122066040EU) have the country code permanently set to Europe. The
WR models (BR-AP122066030WW and BR-AP122066040WW) cannot be
configured for use in the US or Europe.
Operation in the US and Canada
The use on UNII (Unlicensed National Information Infrastructure) Band 1
5150-5250 MHz is restricted to indoor use only, any other use will make the
operation of this device illegal.
