166 Brocade Virtual ADX Graphical User Interface Guide
53-1003242-01
RADIUS servers
9
Creating and editing a RADIUS server
The RADIUS server - new tab allows you to create and edit the settings for a RADIUS server. See
Figure 131.
FIGURE 131 RADIUS server - new tab
Table 31 describes the RADIUS server - new tab controls and their functions.
To create or edit a RADIUS server on this device:
1. Select the Configure tab.
2. Click Security in the tab menu bar.
3. From the sidebar, select RADIUS.
4. At the bottom of the RADIUS Settings tab, click Servers to open the Servers tab.
TABLE 31 RADIUS server creation/ editing tab controls
Control Description
RADIUS Server host IP IP address of the RADIUS server
RADIUS Key RADIUS password key. (1 — 32 chars)
Authentication port Port used for authenticating the server. (range 1–65535, default is 1645)
Accounting port Port used for the Server Account. (range 1–65535, default is 1646)
Server Role Role for the server. Options are Any AAA Operation, Accounting Only, and
Authentication Only.
Encryption If marked, encryption is to be used.
