TACACS controls
9
5. At the bottom of the RADIUS Servers tab, perform either of the following:
• To create a new server, click New to open the new server tab.
NOTE
If there are already 8 servers listed, the New button will be dimmed and not available. You will
have to delete a server from the list before you can add a new one.
• To edit an existing server, select the server entry that you want to modify, and click Edit.
This opens the Edit tab for that server.
6. Provide or edit the following settings:
• Enter the RADIUS Server host IP.
• Enter the RADIUS Key.
• Select the Authentication port.
• Select the Accounting port.
• Select the Server Role.
• If communications with the server are to be encrypted, mark the Encryption Enabled
check box.
7. Click Apply at the bottom right corner of the window to save your settings, or click Reset to
discard any changes you have made and return to the Servers tab.
TACACS controls
This panel provides controls for configuring Terminal Access Controller Access-Control System
(TACACS) server.
By default, only the TACACS Settings tab is displayed when you first open this control set; the other
tabs for the TACACS controls are displayed by clicking their respective buttons at the bottom of the
page. Click on the links below to jump to a description of the features of that tab.
• TACACS Settings tab
• Providing TACACS settings
NOTE
The Server Role options are only available if TACACS+ is in use. If it is not, then they are dimmed
(greyed out) and none are selected.
