180 Brocade Virtual ADX Graphical User Interface Guide

53-1003242-01

Interface statistics

For more information on interface details, refer to the Brocade Virtual ADX Switch and Router

Guide.

Speed Displays the current speed on the selected interface.

Duplex Type Displays the current type of duplex on the selected interface.

Active Trunk Displays the state of active trunk on the selected interface. The active trunk

status can be one of the following:

• Enabled

• Disabled

Tag Mode Displays whether the selected interface is tagged or untagged.

MTU Displays the Maximum Transmission Unit (MTU) for the selected interface.

Statistics

Bit Rate Displays the number of bits received and transmitted per load interval on the

selected interface.

Packet Rate Displays the number of packets received and transmitted per load interval on

the selected interface.

Utilization% Displays the percentage utilization of the selected interface for receiving and

transmitting information.

Bytes Displays the number of bytes received and transmitted on the selected

interface.

Packets Displays the number of packets received and transmitted on the selected

interface.

Unicast Packets Displays the number of unicast packets received and transmitted on the

selected interface.

Broadcast Packets Displays the number of broadcast packets received and transmitted on the

selected interface.

Multicast Packets Displays the number of multicast packets received and transmitted on the

selected interface.

Errors

Errors Received Displays the total number of errors received on the selected interface.

Errors Transmitted Displays the total number of errors transmitted by the selected interface.

Collisions Transmitted Displays the total number of collisions transmitted by the selected interface.

Runt Packets Received Displays the total number of runt packets received on the selected interface.

Giant Packets Received Displays the total number of giant packets received on the selected interface.

Frame Errors Received Displays the total number of frame errors received on the selected interface.

CRC Errors Received Displays the total number of Cycle Redundancy Check (CRC) errors received on

the selected interface.

IP Address(es)

Displays the IP address of the interface.

TABLE 39 Interface Details page (Continued)

Field Description
