190 Brocade Virtual ADX Graphical User Interface Guide

53-1003242-01

IPv6 Neighbor

The following table describes the fields available in the UDP page.

For more information on UDP statistics, refer to the Brocade Virtual ADX Switch and Router Guide.

IPv6 Neighbor

The IPv6 Neighbor Summary page displays the IPv6 neighbors configured on the device. Each entry

lists the IPv6 neighbor address, VLAN, link-layer address, state, age, port, and type.

To view IPv6 neighbors configured on the device, perform the following steps within the Monitor

tab.

1. Click Network on the menu bar.

2. From the sidebar, select IPv6 Neighbor.

The IPv6 Neighbor Summary page is displayed.

This tab has a table listing all the recorded attributes for that IPv6 Neighbor connection.

TABLE 47 UDP page - fields and descriptions

Field Description

Received Displays the number of UDP packets received.

Sent Displays the number of UDP packets sent.

Invalid Port Displays the number of UDP packets dropped because of invalid

UDP port number.

TABLE 48 IPv6 Neighbor connection - recorded attributes

Column Content

IPv6 Address IPv6 address of the route's destination.

VLAN VLAN ID for this connection.

Link Layer Address IPv6 link layer address.

State State of the connection.

Age Age of the connection in days.

Port Port that this IP address is connected to.

Type Type of connection (Router, Switch).
