Brocade Virtual ADX Graphical User Interface Guide 199

53-1003242-01

ARP cache statistics

The following table describes the fields available in the ARP page.

The ARP Cache page displays a list of all cache information in table. Each cache includes IP and

MAC address, port, type and age of the cache. Click Next or Previous to navigate the list or select

First or Last to jump to the most recent or least recent entries respectively.

You can filter the information displayed in the ARP cache table using the Filter icon in the top right

corner of the main page. Click the icon to view the filtering panel and search the information based

on the Filter Criteria.

For more information on ARP statistics, refer to the Brocade Virtual ADX Switch and Router Guide.

TABLE 57 ARP page - fields and descriptions

Field Description

Statistics

Requests Received Displays the total number of incoming requests.

Requests Sent Displays the total number of requests sent.

Packets Received Displays the total number of packets received.

Replies Sent Displays the total number of replies sent.

Invalid Destination Packets Displays the total number of packets with invalid target protocol

address.

Invalid Source Packets Displays the total number of packets with invalid sender protocol

address.

Pending Packets Dropped Displays the total number of pending packets discarded.

ARP Cache

IP Address Displays the IP address of the Brocade Virtual ADX.

MAC Address Displays the MAC address of the Brocade Virtual ADX.

Port/Trunk Displays the port on which the entry was learned.

Type Displays the type of the ARP entry. The type can be one of the

following:

• Dynamic — Indicates the Brocade Virtual ADX is learned from

an incoming packet.

• Static — Indicates the Brocade Virtual ADX loaded the entry

from the static ARP table when the Brocade Virtual ADX was

connected to other device.

Age (sec) Displays the number of seconds the entry has remained unused. If

this value reaches the ARP aging period, the entry is removed from

the cache.
