202 Brocade Virtual ADX Graphical User Interface Guide

53-1003242-01

Global traffic

The following table describes the fields available in the Global Traffic page.

TABLE 59 Global Traffic page - fields and descriptions

Field Description

Session Traffic

New Session Syncs Sent Displays the new synchronized packets sent for new sessions.

New Session Syncs Received Displays the new synchronized packets received for new sessions.

Sessions Removed Displays the number of sessions removed from the delete queue.

Sessions in Delete Queue Displays the number of sessions in the delete queue.

FWD Sessions Not Found Displays the number of forward sessions that are not found.

Sessions Force Deleted Displays the number of sessions that were forcefully deleted.

Duplicate Sessions Displays the number of duplicate sessions.

Server Traffic

Client to Server (Pkts) Displays the number of packets sent from clients to servers.

Server to Client (Pkts) Displays the number of packets sent from servers to clients.

Aged Sessions Displays the number of TCP and UDP sessions that are closed by

the

Brocade Virtual ADX due to aged out.

Old Connections Displays the number of old connections.

FWD To Non-Static FID Displays the number of forward to non-static FID.

Dropped VIP Pings Displays the number of dropped virtual server (VIP) ping packets.

Unsuccessful Connections Displays the number of unsuccessful connections.

Server Resets Displays the number of server resets.

Dropped Packets

Total Drops Displays the number of packets dropped by the Brocade Virtual

ADX.

Disabled Drops Displays the number of packets the

Brocade Virtual ADX dropped

because they were sent by a client to a VIP port that is bound to a

real server port that is currently disabled.

Forward Drops Displays the number of client-to-server packets dropped by the

Brocade Virtual ADX.

Reverse Drops Displays the number of server-to-client packets dropped by the

Brocade Virtual ADX.

Stale Drops Displays the number of TCP SYN packets dropped by the Brocade

Virtual ADX because they matched a stale session entry.

Exceeded Drops Displays the number of packets dropped by the Brocade Virtual

ADX because the TCP SYN limit on the real server had been

reached.
