Brocade Virtual ADX Graphical User Interface Guide 209

53-1003242-01

Virtual servers

Status Displays the runtime health of the virtual server port. The status

can be one of the following:

• Healthy

• Unhealthy

Admin State Displays the admin state of the virtual server port. The status can

be one of the following:

• Enabled

• Disabled

Concurrent Displays the state of the concurrent sessions that are additionally

opened. The states can be one of the following:

• No

• Yes

DSR Displays the state of the Direct Server Return (DSR) in the virtual

server port. The states can be one of the following:

• No

• Yes

Rx (kbps) Displays the number of packets the Brocade Virtual ADX has

received from the port in kilobits per second.

Tx (kbps) Displays the number of packets the Brocade Virtual ADX has sent

to the port in kilobits per second.

Current Connections Displays the current connections open on the virtual server port.

Peak Connections Displays the highest number of connections reached by the port

over a period of time.

Total Connections Displays the total number of connections on this port.

Proxy Displays the proxy details for the port.

Real Servers bound to this Virtual Server Port

Name Displays the name of the real server to which the port is bound.

Port Displays the name of the real server port.

Status Displays the status of the port on the real server. The status can be

one of the following:

• Enabled

• Disabled

Admin State Displays the admin state of the real server port. The status can be

one of the following:

• Enabled

• Disabled

Current Connections Displays the number of client connections currently on the server.

Current Connection Rate Displays the number of client connections rate currently on the

virtual server port.

Rx Packets Displays the number of packets received by the real server port

bound to this virtual server port.

Tx Packets Displays the number of packets transmitted by the real server port

bound to this virtual server port.

TABLE 63 Virtual Server Port Details page - fields and descriptions (Continued)

Field Description
