Real servers

For more information on real server statistics, refer to the Brocade Virtual ADX Server Load

Balancing Guide.

Transmit Packets Displays the total number of packets transmitted by the port.

Received Bytes Displays the total number of bytes received on the port.

Transmit Bytes Displays the total number of bytes transmitted by the port.

Rx (kbps) Displays the number of packets received by the port in kilobits per

second.

Tx (kbps) Displays the number of packets transmitted by the port in kilobits

per second.

Total Connections Displays the total number of client connections on the server since

the Brocade Virtual ADX was last booted.

Current Connections Displays the number of client connections currently on the real

server port.

Virtual Servers bound to this Real Server Port

Name Displays the name of the virtual servers.

Port Displays the name of the virtual server ports.

Address Display the IP address of the virtual server to which the port is

bound.

Status Displays the runtime health of the virtual server ports. The status

can be one of the following:

• Enabled

• Disabled

Admin State Displays the admin state of the virtual server port. The status can

be one of the following:

• Enabled

• Disabled

Current Connections Displays the number of client connections currently on the virtual

server.

Current Connection Rate Displays the rate of TCP traffic per second for the current

connection.

Rx Packets Displays the number of packets the Brocade Virtual ADX has

received from the server.

Tx Packets Displays the number of packets the Brocade Virtual ADX has sent

to the server.

TABLE 67 Real Server Port Details page - fields and descriptions (Continued)

Field Description
