Brocade Virtual ADX Graphical User Interface Guide 219
53-1003242-01
Content switching
13
DNS DPI policy
Click DNS DPI Policy tab to view the statistics of the DNS DPI policies and the rules associated with
each policy. Select the policy from the table to view the rules associated with this policy.
The DNS DPI Policy tab is displayed.
The following table describes the fields available in the DNS DPI policy tab.
DNS DPI policy details
On the DNS DPI tab, select a policy and click Details at the bottom of the tab. The details of the
DNS DPI Policy Rules tab appears.
The following table describes the fields available in the DNS DPI Policy Rules tab.
TABLE 70 DNS DPI policy tab - fields and descriptions
Field Description
Name
Displays the name of the DNS policy.
Bind Count Displays the number of DNS policies bound to the virtual server
port.
TABLE 71 DNS DPI Policy Rules tab - fields and descriptions
Field Description
Rule Name Displays the rule name associated with the policy.
Action Type Display the action performed by the Brocade Virtual ADX based on
the incoming packet.
Flag Displays the information about the actions of the rule.
Hit Count Displays the number of times the rule is matched.
