Brocade Virtual ADX Graphical User Interface Guide 223
53-1003242-01
OpenScript
13
The following table describes the fields available in the OpenScript page.
Detailed OpenScript statistics
To view the detailed statistics of an OpenScript, perform the following steps within the Monitor tab.
1. Click Traffic on the menu bar.
2. From the sidebar, select OpenScript.
3. Select a script from the table in the OpenScript page and click Details.
The Details page is displayed, as shown in Figure 157.
FIGURE 157 Displaying OpenScript details
TABLE 74 OpenScript page - fields and descriptions
Field Description
Name Displays the name of the script.
Virtual Server Displays the name of the virtual server.
Port Displays the name of the port to which the script is bound.
Script Status Displays the status of the script.
Memory Threshold Exceeded Displays the number of BPs that have exceeded the memory
threshold percentage set in the corresponding script profile.
