(Supporting ADX v03.1.00) Owner's manual

230 Brocade Virtual ADX Graphical User Interface Guide
53-1003242-01
SSL statistics
14
The following table describes the fields available in the Other Attacks Details page.
SSL statistics
The Secure Socket Layer (SSL) page has the auto refresh interval option as On Demand. The
information in the SSL page is refreshed when you click the Refresh icon. This page is enabled only
if you installed the appropriate SSL license.
To display the SSL statistics, perform the following steps within the Monitor tab.
1. Click Security on the menu bar.
2. From the sidebar, select SSL.
The SSL page is displayed, as shown in Figure 163.
TABLE 79 Other Attacks Details page -fields and descriptions
Field Description
Statistics
Attack Packets Dropped Displays the total number of attack packets dropped based on individual attack
packet types.
Attack Packets Logged Displays the total number of attack packets logged.
Attack Types
Attack Type Displays the type of the attack. The types can be one of the following:
• XMas Tree
• SYN Fragments
• SYN And FIN Set
• Deny All Fragments
• FIN With No ACK
• ICMP Fragments
• Ping Of Death
• Large ICMP
• Land Attack
• IP Unknown Protocol
• NO TCP Flags
Attack Drop Count Displays the total number of attack packets dropped based on each individual
attack packet types.
Attack Log Count Displays the total number of attack packets logged.
