232 Brocade Virtual ADX Graphical User Interface Guide
53-1003242-01
SSL statistics
14
SSL alerts
To display the SSL alerts statistics, perform the following steps within the Monitor tab.
1. Click Security on the menu bar.
2. From the sidebar, select SSL, and then select SSL Alerts.
The SSL Alerts page is displayed, as shown in Figure 164.
FIGURE 164 Displaying the SSL alerts
Hash Statistics
MD5 Raw Hash Calls Displays the number of calls made by the device using Message Digest
(MD5) raw hash algorithm.
SHA1 Raw Hash Calls Displays the number of calls made by the device using Secure Hash
(SHA1) raw hash algorithm.
SSL MAC MD5 Calls Displays the number of SSL calls made by the device using MAC MD5.
TLS MAC MD5 Calls Displays the number of TSL calls made by the device using MAC MD5.
SSL MAC SHA1 Calls Displays the number of SSL calls made by the device using MAC SHA1.
TLS MAC SHA1 Calls Displays the number of TLS calls made by the device using MAC SHA1.
Data Encryption Statistics
Triple DES Calls Displays the number of triple Data Encryption Standard (DES) calls made
by the device.
RC4 Calls Displays the number of RC4 calls made by the device.
TABLE 80 SSL page - fields and descriptions (Continued)
Field Description
