236 Brocade Virtual ADX Graphical User Interface Guide

53-1003242-01

SSL statistics

SSL Connections Failed Displays the number of attempts failed during SSL connect.

Client Authorization Successful Displays the number of sessions authorized by the client.

Client Authorization Failed Displays the number of sessions failed during client authorization.

SSL Session Reuse Attempts Displays the number of attempts for SSL session reuse.

SSL Session Reuse Failed Displays the number of attempts failed for SSL session reuse.

SSL Close Count Displays the number of SSL sessions closed.

SSL Remote Close Count Displays the number of remote SSL sessions closed.

SSL Reset Count Displays the number of SSL sessions reset.

SSL Remote Reset Count Displays the number of remote SSL sessions reset.

SSL Certificate Verification Statistics

Certificate Verification Successful Displays the number of times the certificate verification was

successful.

Certificate Verification Failed Displays the number of times the certificate verification failed.

Unknown User Displays the number of times the user is identified as unknown

user.

Certificate Verification Signature Failed Displays the number of times the certificate verification signature

failed.

Certificates Expired Displays the number of expired certificates.

Certificates Revoked Displays the number of revoked certificates.

Certificates Not Yet Valid Displays the number of times the certificate was not yet valid.

Certificate Signature Failed Displays the number of times the certificate signature failed.

Issuer Public Key Decode Failed Displays the number of times the decode of issuer public key

failed.

Self Signed Certificates Displays the number of self-signed certificate.

Issuer Certificate Not Found Displays the number of times the issuer certificate was not found.

Certificate Untrusted Displays the number of untrusted certificates.

Certificate Chain Too Long Displays the number of times the certificate chain was too long.

Certificate Not Sent By Peer Displays the number of times the certificate was not sent by peer.

Certificate Revocation List (CRL) Statistics

CRL Load Failed Displays the number of times the CRL load failed.

CRL Signature Failed Displays the number of times the CRL signature failed.

CRL Not Found Displays the number of times the CRL was not found.

CRL Not Yet Valid Displays the number of times the CRL was not yet valid.

CRL Expired Displays the number of times the CRL had expired.

TABLE 83 SSL Client Details page - fields and descriptions (Continued)

Field Description
