Brocade Virtual ADX Graphical User Interface Guide 237

53-1003242-01

Chapter

Maintenance Overview

In this chapter

•Navigating the maintain tab . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 237

Navigating the maintain tab

The Maintain tab is the fourth or last tab in the Brocade Virtual ADX web interface. You can use the

menus that are available in the Maintain tab to perform the following actions:

• Software Upload — Allows you to upload the software on the device from the Trivial File Transfer

Protocol (TFTP) Server and reboot from that image.

• Reboot — Allows you to reboot the Brocade Virtual ADX.

• License — Allows you view the existing licenses, add new licenses, and delete licenses.

• Packet Capture — Allows you to perform Packet Capture.

• CLI Access — Allows you to run the CLI commands to configure the features that are not

supported in the web interface.

• Technical Support — Allows you to view and download the Brocade Virtual ADX information that

can help Brocade Technical support team to troubleshoot your system.
