246 Brocade Virtual ADX Graphical User Interface Guide
53-1003242-01
Packet capture
19
The Packet Capture Summary tab displays the following fields described in Table 85.
Use the Packet Capture Summary page to:
• Click the Edit Filter button to navigate to the “Edit Filter” page to edit filters.
• Click the Apply Filter button to apply filters.
Edit Filter
Take the following steps within the Maintain tab to edit a filter:
1. Select the Maintain tab.
2. Click Tools on the menu bar.
3. From the sidebar, select Packet Capture to display the Packet Capture Summary tab.
TABLE 85 Packet Capture Summary tab - fields and descriptions
Field Description
Applied Filter The applied filter.
Applied On The default is for the filter to be applied on BP and MP.
Buffer Size The total allotted buffer size is 32768 kb.
Packet Size 64-9234
Status Indicates if a packet capture session is running.
Port The default is for the filter to be applied on all ports. The port field returns the
corresponding string.
Type The type of port.
