Brocade Virtual ADX Graphical User Interface Guide 255

53-1003242-01

Appendix

Troubleshooting

In this appendix

•Unable to open web interface. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 255

•Web interface does not reflect changes based on the latest image . . . . . 256

•RSL error (#2032 Stream Error) when launching the web interface . . . . . 256

Unable to open web interface

Problem

The Brocade Virtual ADX web interface does not open.

Solution

Verify the following items to resolve this problem:

• Make sure that the following services are enabled on the device:

- Hypertext Transfer Protocol (HTTP)

- Simple Object Access Protocol (SOAP)

- Secure HTTP (HTTPS)

The HTTP and SOAP services are enabled by default. However, to enable HTTPS, ensure that

the device supports SSL and then generate a SSL certificate. The SSL protocol uses digital

certificate and a private-public key pair to establish a secure connection. To enable SOAP

service, run the following command in the CLI.

VirtualADX# web-management soap-service

• Make sure that the web-management services are enabled in the Brocade Virtual ADX. If not,

after entering the privilege mode, run the following command in the CLI to enable the

web-management services.

VirtualADX# web-management enable

VirtualADX# web-management http

VirtualADX# web-management https

VirtualADX# crypto-ssl certificate generate default_cert
