XML schema element reference
B
System schema elements
TABLE 89 System schema elements
Element Type Description Rules / Notes
ADXTemplate.system container The section for ADX
system settings
Optional
system.hostname string The host name for the
ADX system
Optional
system.hostname.@variable string
attribute
The name of a variable
that will provide the
hostname of the ADX
system
Must refer to an existing variable
of type "string" or
"stringNoWhiteSpace"; optional
system.suPassword string The administrative
password for the ADX
Optional
system.aaaOnConsole boolean Should AAA be allowed on
consoles
Default is false; optional
system.allowTelnet boolean Should telnet access be
allowed
Default is false; optional
system.hotStandby container Hot Standby settings Optional
hotStandby.active boolean Hot Standby active flag
hotStandby.vlan integer Hot Standby VLAN id 1 to 4095 (or configured VLAN
maximum if it is smaller); must
also match an existing VLAN id in
the "vlans" section of this
template
hotStandby.ethernetPort integer Hot Standby ethernet
port
1 to 64, or possibly less than 64
depending on the valid port
numbers of the current ADX
hotStandby.
redundancyPort
integer Hot Standby redundancy
port
1 to 64, or possibly less than 64
depending on the valid port
numbers of the current ADX
hotStandby.peer MAC
address
Hot Standby peer
system.security container Security settings Optional
