XML schema element reference
B
network.staticRoutes container A collection of Static
Route definitions
Optional
staticRoutes.staticRoute container A single Static Route Multiple "staticRoute"
elements are allowed; up
to 32 maximum
staticRoute.destinationIp IP address The address of the
route
staticRoute.subnetMask IP address The subnet mask of
the route
staticRoute.route container The details of the
route
Must contain exactly one
of the following
sub-elements:
• nextHop
• ethernet
• null0
• ve
route.nextHop IP address The IP address of next
hop
route.ethernet string An ethernet port Maximum length
3characters
route.null0 boolean The "null0" indicator Always set to "true" when
used
route.ve integer The number of a "VE”
network.vlans container A collection of VLAN
definitions
Optional
vlans.vlan container A single VLAN Multiple "vlan" elements
are allowed
vlan.id integer The VLAN id 1 to 4095 (or configured
VLAN maximum if it is
smaller)
vlan.name string The VLAN name Maximum length
32 characters; optional
vlan.byPort boolean The VLAN "by port"
flag
Default false; optional
vlan.tagged container The tagged ports Optional
tagged.ethernets container The tagged ethernet
ports
A collection of port
numbers and/or ranges
ethernets.port integer The number of one
tagged ethernet port
1 to 64, or possible less
than 64 depending on the
valid port numbers of the
current ADX
ethernets.portRange container A range of tagged
ethernet ports
TABLE 90 Network schema elements (Continued)
Element Type Description Rules / Notes
