XML schema element reference
B
Virtual server schema elements
<repeater count="RS_NAMES">
<real>
<name variable="RS_NAMES"/>
<ip variable="RS_IPS"/>
<realPorts>
<realPort>
<port>http</port>
<serverId variable="SERVER_ID"/>
<groupIds>
<groupId >
<from>1</from><to>1</to>
</groupId >
</groupIds>
<http> <!-- http-specific settings -->
<url>HEAD /</url>
</http>
</realPort>
<realPort>
<port>ssl</port>
<serverId variable="SERVER_ID"/>
<groupIds>
<groupId >
<from>1</from><to>1</to>
</groupId >
</groupIds>
</realPort>
<realPort><port>135</port></realPort>
<realPort><port>60000</port></realPort>
<realPort><port>60001</port></realPort>
</realPorts>
</real>
</repeater>
</reals>
</slb>
</ADXTemplate>
TABLE 93 Virtual server schema elements
Element Type Description Rules / Notes
ADXTemplate.slb container The section for SLB Optional
slb.virtuals container The section for Virtual
Servers
Optional
virtuals.virtual container A single Virtual Server Multiple "virtual" elements
are allowed up to 10
maximum
virtual.name string The Virtual Server name 42 characters maximum
virtual.name.@variable string attribute The name of a variable
that provides the Virtual
Server name
Must refer to an existing
variable of type "string" or
"stringNoWhiteSpace";
optional
virtual.ip IP address The Virtual Server IP
address
40 characters maximum,
either IPv4 or IPv6 allowed
