XML schema element reference
B
virtual.ip.@variable string attribute The name of a variable
that provides the Virtual
Server IP Address
Must refer to an existing
variable of type
"ipAddress" or
"ipAddressNonBlank";
optional
virtual.context string The context in which to
create the Virtual Server
If unspecified, "default"
context is used; optional
virtual.predictor predictor The Virtual Server
predictor
• dynamic-weighted-direct
• dynamic-weighted-revers
e
• enhanced-weighted
• least-conn
• response-time
• round-robin
• weighted
• weighted-round-robin
• weighted-round-robin-sta
tic
virtual.predictor.@variable string attribute The name of a variable
that provides the Virtual
Server predictor
Must refer to an existing
variable of type "predictor";
optional
virtual.predictorOid integer The predictor OID 1 to 255; required for
"dynamic-weighted-direct"
and
"dynamic-weighted-reverse
"; ignored for all other
predictor types
virtual.predictorMax integer The predictor OID
maximum
0 to 4294967295;
required for
"dynamic-weighted-direct"
and
"dynamic-weighted-reverse
"; ignored for all other
predictor types
virtual.tosMarking container Settings for TOS Marking Optional
tosMarking.value integer The TOS Marking value 1 to 63
tosMarking.hcL3Dsr boolean The Health Check L3 DSR
flag
Default is false; optional
virtual.virtualPorts container A collection of Virtual Ports
virtualPorts.virtualPort container A single Virtual Port Multiple "virtualPort"
elements are allowed up to
10 maximum
TABLE 93 Virtual server schema elements (Continued)
Element Type Description Rules / Notes
