XML schema element reference
B
realBinding.realPort port-or-protocol-
number
The name of a well known
port or a protocol number
for the bound Real Server
• http
• https
• ssl
• dns
• ftp
• ldap
• ldaps
• tftp
• ssh
• 1 to 65535
realBinding. realPort.@variable string attribute The name of a variable
that provides the Real Port
name or number
Must refer to an existing
variable of type
"portOrProtocol"; optional
realBinding.associatedRealPort port-or-protocol-
number
The name of a well known
port or a protocol number
of an associated port on
the bound Real Server
• http
• https
• ssl
• dns
• ftp
• ldap
• ldaps
• tftp
• ssh
• 1 to 65535
Optional
realBinding.
associatedRealPort.@variable
string attribute The name of a variable
that provides the
associated Real Port name
or number
Must refer to an existing
variable of type
"portOrProtocol"; optional
realBindings.repeater container A repeater used for
creating multiple
Virtual-to-Real Port
Bindings
Multiple "repeater"
elements are allowed up to
4 maximum
repeater.@count string attribute The name of a variable
that provides the repeater
count
The variable must either
have a number or a list
that can be tallied;
mandatory
repeater.realBinding container A single Virtual-to-Real Port
Binding within the
repeater;
refer to the "realBinding"
details above
Multiple "realBinding"
elements are allowed up to
32 maximum
TABLE 93 Virtual server schema elements (Continued)
Element Type Description Rules / Notes
