XML schema element reference
B
persist.
realPort
container The "Real Port" of a
"persist" action
Optional
realPort.port port-or-protocol
-number
The name of a well known
port or a protocol number
• http
• https
• ssl
• dns
• ftp
• ldap
• ldaps
• tftp
• ssh
• 1 to 65535
realPort.failClose boolean The "fail close" flag "failClose" and
"portFailover" are mutually
exclusive, both cannot be
used together; optional
realPort.portFailover boolean The "port failover" flag "failClose" and
"portFailover" are mutually
exclusive, both cannot be
used together; optional
persist.secondary boolean The "secondary" flag Optional
details.passivePersist container The details of a
"passive-persist" action
passivePersist.offset integer The offset of a
"passive-persist" action
0 to 4294967295
passivePersist.end container The end indicator of a
"passive-persist" action
Must contain either a
"length" or "terminator" sub
element, but not both
end.length integer The length of a
"passive-persist" action
0 to 4294967295;
"length" and "terminator"
are mutually exclusive
end.terminator string The terminator of a
"passive-persist" action
32 characters maximum;
"length" and "terminator"
are mutually exclusive
details.redirect container The details of a "redirect"
action
redirect.domain string The redirect domain 80 characters maximum
redirect.url string The redirect URL 80 characters maximum
TABLE 96 CSW request policies schema elements (Continued)
Element Type Description Rules / Notes
