Brocade Virtual ADX Graphical User Interface Guide 303

53-1003242-01

XML schema element reference

Example XML Content: CSW response rules schema elements

body.operation enumerated

string

The kind of test

operation to perform on

the body

• equals

• exists

• pattern

• prefix

• search

• suffix

body.value string The value to test for in

the operation

Required for all operation

types except "exists"

responseRule.caseInsensitive boolean The case-insensitive flag Default is false; optional

TABLE 97 CSW response rules schema elements (Continued)

Element Type Description Rules / Notes

<ADXTemplate xmlns:xsi=http://www.w3.org/2001/XMLSchema-instance

xsi:noNamespaceSchemaLocation="ADXTemplate.xsd">

<slb>

<csw>

<name>response-rule-status-code</name>

<type>status-code</type>

</statusCode>

</details>

</responseRule>

<name>response-rule-header-suffix</name>

<type>header</type>

<headerName>my-response-header</headerName>

<operation>suffix</operation>

<value>suffix-value</value>

</header>

</details>

</responseRule>

<name>response-rule-body-pattern</name>

<body>

<operation>pattern</operation>

<value>pattern-value</value>

</body>

</details>

</responseRule>

</responseRules>

</csw>

</slb>

</ADXTemplate>
