(Supporting ADX v03.1.00) Owner's manual

304 Brocade Virtual ADX Graphical User Interface Guide
53-1003242-01
XML schema element reference
B
CSW response policies schema elements
TABLE 98 CSW response policies schema elements
Element Type Description Rules / Notes
csw.responsePolicies container A collection of Response
Policies
Optional
responsePolicies.responsePolicy container A single Response Policy Multiple responsePolicy
elements are allowed;
unlimited except for
available
dynamically-allocated
memory
responsePolicy.name string The Response Policy
name
80 characters maximum
responsePolicy.context string The context in which to
create the policy
If unspecified, "default"
context is used; optional
responsePolicy.actions container The Response Policy
actions
Must contain one or more
"action" sub-elements
actions.action container A single Response Policy
action
A mapping of a Response
Rule to an action to
perform
action.ruleName string The name of a Response
Rule
80 characters maximum;
must match the name of
an existing Response Rule
within this template
action.ruleName.
@default
boolean The "default rule" flag If "true", the rule name is
ignored and the rule is
treated as a "default rule"
match
action.actionType enumerated
string
The type of action to
perform
• response header
rewrite
• response body
rewrite
• response header
replace
• response body
replace
action.rewriteReplace container The details for replace
actions
This element is only used
for "response body
replace" and "response
header replace", otherwise
this element should be
omitted
rewriteReplace.
string
string The replace string 80 characters maximum
rewriteReplace.
offset
integer The replace offset
rewriteReplace.
length
integer The replace length
responsePolicy.caseInsensitive boolean The case-insensitive flag default is false; optional
