XML schema element reference
B
profile.keyPairFile string The Key Pair file name 32 characters maximum; the Key
Pair file must already be installed
on the ADX, optional
profile.certFile string The Cert file name 32 characters maximum; the Cert
file must already be installed on
the ADX, optional
profile.caCertFiles container The list of CA Certs Multiple caCertFile elements are
allowed up to 4 maximum,
optional
profile.caCertFile string The CA Cert name 32 characters maximum; the CA
Cert must already be installed on
the ADX
profile.cipherSuites container A list of ciphers to use Multiple cipherSuite elements are
allowed up to 16 maximum,
optional
profile.
cipherSuite
enumerated
string
A type of cipher to use
• all-cipher-suites
• rsa-export-with-des40-cbc-sha
• rsa-export-with-rc2-cbc-md5
• rsa-export-with-rc4-40-md5
• rsa-with-3des-ede-cbc-md5
• rsa-with-3des-ede-cbc-sha
• rsa-with-aes-128-sha
• rsa-with-aes-256-sha
• rsa-with-des-cbc-md5
• rsa-with-des-cbc-sha
• rsa-with-rc2-cbc-md5
• rsa-with-rc4-128-md5
• rsa-with-rc4-128-sha
profile.chainCaCert boolean The CA Cert Chain flag Default is false; optional
profile.sessionCache container Session cache settings Optional
sessionCache.enabled boolean The session cache
enabled flag
Default is true; optional
sessionCache.maxEntries integer Maximum number of
entries
512 to 8192; optional
sessionCache.Timeout integer Timeout durations 30 to 86400; optional
profile.tcpProfile string The TCP Profile name 64 characters maximum; the TCP
Profile file must already exist
within this template, optional
TABLE 100 SSL server schema elements (Continued)
Element Type Description Rules / Notes
