XML schema element reference
B
Example XML content: CLI schema elements
NOTES: Consider the following when using CLI schema elements:
• Only configuration mode commands are allowed.
• The commands between <commands> tags should be properly aligned.
• Be cautious when using the exit command. More than one exit command could bring
the command execution mode out of configuration mode.
• Brocade recommends that you prefix an empty space to commands at a level 2 or
more, for example:
commandSet.@before boolean The "before" attribute flag If "true", this is to allow this
set of commands to be
executed before the
template settings are
applied; default is "true",
optional.
commandSet.commands string The CLI commands to
execute
Must not be blank. Ensure
that these commands are
valid and of proper syntax.
TABLE 101 CLI schema elements (Continued)
Element Type Description Rules / Notes
<ADXTemplate xmlns:xsi=http://www.w3.org/2001/XMLSchema-instance
xsi:noNamespaceSchemaLocation="ADXTemplate.xsd">
<cli>
<commandSet before="true">
<commands>
server active-active-port ethe 1
server symmetric-port ethernet 2
config-sync mode sender
config-sync ethernet 16 mac 001b.ed3c.b18f vlan-id 16
server session-limit 2000000
server reassign-threshold 20
no server no-reassign-count
</commands>
</commandSet>
<commandSet after="true">
<commands>
server predictor response-time
server syn-cookie-attack-rate-threshold 200
server clock-scale 3
no server l4-check
port-range telnet
</commands>
</commandSet>
</cli>
</ADXTemplate>
interface ethernet 1
ipv6 address 34::45/32
