Unpack the machine and check the components

NOTE:

• The components included in the box may differ depending on

your country.

• The available connection interfaces vary depending on the

model.

• Interface cables are not included. You must purchase the

correct interface cable if you require one.

USB cable

We recommend using a USB 2.0 cable (Type A/B) that is

no more than 2 metres long.

Network cable

Use a straight-through Category 5e (or greater) twisted-

pair cable.

• The illustrations in this Quick Setup Guide show the

MFC-L8900CDW.

Remove the packing materials and install the drum unit and toner cartridge assembly

Load paper in the paper tray

Connect the power cord and turn the machine on

Select your language (if needed)

(Only for certain models)

Drum Unit* Waste Toner Box* Belt Unit*

(For U.K.) (For Others)

Inbox Toner Cartridges*

(Black, Cyan, Magenta and

Yellow)

Telephone Line Cord

(For MFC models)

AC Power Cord

Telephone Line Cord Adapter

(Australia only)

(For MFC models)

Brother Installation Disc Quick Setup Guide Product Safety Guide

Reference Guide

(only for certain models)

Adjust the paper

guides.

Back Front

1. On the machine’s Touchscreen, press [Settings] * > [All Settings] >

[Initial Setup] > [Local Language].

2. Press your language.

3. Press .

* [Settings] menu is for DCP-L8410CDW and MFC-L8690CDW.

Do not exceed this mark.

* Already installed in the machine

Watch our Video FAQs for

help with setting up your

Brother machine:

solutions.brother.com/videos.

Remove the packing tape.

Select your country/language

(Initial setup only)

After turning the machine on, you may be required to set your country

or language (depending on your machine).

If required, follow the on-screen instructions.

Quick Setup Guide

DCP‑L8410CDW / MFC‑L8690CDW / MFC‑L8900CDW /

MFC‑L9570CDW

Read the Product Safety Guide first, then read this Quick

Setup Guide for the correct installation procedure.

Not all models are available in all countries.

The latest manuals are available at the Brother Solutions

Center: solutions.brother.com/manuals.

D00EZW001-00

Version 0

Summary of content (2 pages)

PAGE 1
DCP‑L8410CDW / MFC‑L8690CDW / MFC‑L8900CDW / MFC‑L9570CDW Read the Product Safety Guide first, then read this Quick Setup Guide for the correct installation procedure. Not all models are available in all countries. Quick Setup Guide The latest manuals are available at the Brother Solutions Center: solutions.brother.com/manuals.
PAGE 2
6 Select a device to connect to your machine Computer Mobile Device Go to 7 and follow the instructions. Go to Connect your computer and follow the instructions. Brother regularly updates firmware to add features and apply bug fixes. To check for the latest firmware, visit solutions.brother.com/up3. Download Put the installation disc into your CD/DVD drive, or download the Full Driver & Software Package at: Finished Follow the on-screen instructions and prompts.
