BP16 PREAMPLIFIER OWNER’S MANUAL For models BP16, BP16-DA & BP16-P
IMPORTANT SAFETY INSTRUCTIONS The lightning flash with arrowhead symbol within an equilateral triangle, is intended to alert the user to the presence of un-insulated “dangerous voltage “ within the product’s enclosure that may be of sufficient magnitude to constitute a risk of electric shock to persons. The exclamation point within an equilateral triangle is intended to alert the user to the presence of important operating and maintenance (servicing) instructions in the literature accompanying the product.
BP16 PREAMPLIFIER INTRODUCTION: Thank you for purchasing a Bryston BP16 Preamplifier. We are confident it will provide you with many years of musical enjoyment. We would welcome any suggestions or comments you may have regarding the operation of your Bryston amplifier. In the unlikely event that your amplifier may require service Bryston recommends that you retain the original shipping box and packaging material for future use if required.
BP16 PREAMPLIFIER Mode (from Analog Mode). Similarly, when re-entering Analog Mode from Digital Mode the previously selected analog input will be automatically re-selected. See also the DIGITAL-to-ANALOG CONVERTER OPTION section for more information. HEADPHONE JACK: There is a quarter inch headphone output jack available on the front panel of the Bryston BP16 Preamplifier. Inserting the headphone jack mutes Preamp Out automatically.
BP16 PREAMPLIFIER selected the 12Vdc control voltage will be removed from these pins. Please note that C means “common” here and both C pins are electrically connected and identical. PROGRAMMING the HANDHELD REMOTE CONTROL: PROGRAMMING the “T2” 12v TRIGGER OUTPUT: By default the T2 triggered output is inactive.
BP16 PREAMPLIFIER 029 - power on 058 - mute on 059 - mute off 061 - record monitor toggle 062 - record monitor on 063 - record monitor off 081 - select digital source 1 (D1) 082 - select digital source 2 (D2) 083 - select digital source 3 (D3) 084 - select digital source 4 (D4) 245 - set/reset Pass Through mode 247 - Set Trigger 2 for current source 248 - Clear Trigger 2 for current source 255 - System reset; restore defaults Activate the DAC feature by pressing the DIGITAL4Select (AUX 2) button on the lef
BP16 PREAMPLIFIER 6
BP16 PREAMPLIFIER BP16_MANUAL_20060324
