Installation Manual

Dodge Ram 15/25/3500
Bushwacker only approves installing the fl ares according to these
written instructions with the hardware provided. WARNING: Failure
to install according to these instructions will invalidate the warranty.
This includes, but is not limited to using alternative installation
methods, hardware, or materials. DO NOT USE: Loctite, SuperGlue,
or similar products on the hardware or the fl ares.
Fit: Verify the fi t of the fl ares to vehicle. (Some fi ling, sanding, or
cutting may be necessary to ensure proper fi t).
Painting: (Optional) if paint is desired it must be done prior to installing
fl ares on the vehicle. Clean outer surface with a good grade degreaser.
DO NOT USE LACQUER THINNER OR ENAMEL REDUCER AS A
DEGREASER. Wipe outer surface thoroughly with a tack rag prior
to paint. Application of plastic adhesion promoter for ABS plastic as
per your paint system manufacturer’s recommendations is required.
Paint fl ares using a high quality enamel, or polyurethane automotive
paint. If painting edge trim (not recommended), use a fl ex additive.
Performance: Using larger Tires may increase the area required to
turn the vehicle. Some Tire/Rim combinations may require lowering
bump stops and or installing steering stops to prevent tire from
contacting fl are.
Exhaust System: Modifi cations may be necessary to maintain a
minimum 4” clearance between fl ares and exhaust pipes. (Exhaust
gases should not vent directly onto fl ares)
Metal Protection: All exposed fasteners and bare metal should
be treated with rust resistant paint BEFORE installing fl ares. Spray
inner fender wells with undercoating AFTER fl are attachments have
been completed.
Decals: Flares may interfere with existing decals on vehicle. If you
wish, remove decals prior to installation of fl ares.
Utility Knife
#2 Phillips Driver
Socket Wrench
8 mm Socket
1/2” Wrench
Electric Drill
5/16” Drill Bit
Awl or Similar Pointed Tool
Grease Pencil
S Clip,
6 pcs
Plastic Tab,
6 pcs
#8 Pan-Head
Screw, 4 pcs
#10 Truss
Screw, 6 pc
T45 Torx Bit,
1 pc
Nyloc Nut,
38 pcs
Pocket Washer,
38 pcs
Pocket Screw,
38 pcs
Edge Trim,
312 in.
Set Part #50907-02
Rev-8 03-03-10
STEP 1 - PRIOR TO INSTALLATION
TOOLS FOR EASY INSTALLATION:
6710 N CATLIN AVE. • PORTLAND, OR 97203 • 503-283-4335 • 1-800-234-8920 (USA AND CANADA) • FAX [phone]
•
•
•
•
•
•
•
•
•
A)
B)
C)
D)
E)
F)
G)
To claim a warranty, you must provide Proof
of Purchase.
LIMITED LIFETIME WARRANTY AGAINST
ANY MANUFACTURING DEFECTS
•
1.
2.
9.
7.6.5.4.
10.
Included in Hardware Kit
Narrow Clip,
4 pcs
3. 8.
