Printed in Taiwan

Read this manual and follow all the Safety Rules and Operating Instructions before using this product.

This is the safety alert symbol. It is used to alert you to potential personal injury hazards.

Obey all safety messages that follow this symbol to avoid possible injury or death.

! ADVERTENCIA

• Leer, comprender, y seguir las instrucciónes antes

de utilizar el aparato.

• El manual de instrucciónes y la información de

seguridad deben estar comunicado en lengua del

operador antes del uso.

• No seguir estas indicaciónes puede causar daños

personales o materiales.

! WARNING

To avoid crushing and related injuries:

NEVER work on, under or around a

load supported only by a hydraulic

jack. ALWAYS use adequately rated

jack stands.

MODELS: J10500 - 50 Ton Capacity

Hydraulic Bottle Jack

Instruction Manual

SFA Companies 10939 N. Pomona Ave. Kansas City, MO 64153

Tel: 888-332-6419 * Fax: 816-891-6599

E-mail: sales@bvahydraulics.com Website: www.bvahydraulics.com

J10500-M1 rev 07/08

US Patent No. 5,946,912

Summary of content (8 pages)

PAGE 1
J10500-M1 rev 07/08 Hydraulic Bottle Jack Instruction Manual MODELS: J10500 - 50 Ton Capacity SFA Companies 10939 N. Pomona Ave. Kansas City, MO 64153 Tel: 888-332-6419 * Fax: 816-891-6599 E-mail: sales@bvahydraulics.com Website: www.bvahydraulics.com ! This is the safety alert symbol. It is used to alert you to potential personal injury hazards. Obey all safety messages that follow this symbol to avoid possible injury or death. US Patent No.
PAGE 2
SAFETY and GENERAL INFORMATION Save these instructions. For your safety, read, understand, and follow the information provided with and on this jack before using. The owner and operator of this equipment shall have an understanding of this jack and safe operating procedures before attempting to use. The owner and operator shall be aware that use and repair of this product may require special skills and knowledge.
PAGE 3
! WARNING ! WARNING X • Study, understand, and follow all printed materials provided with/on this product before use. • Do not exceed rated capacity. • This is a lifting device only! • Immediately after lifting, support the load with a pair of appropriately rated jack stands. • Use only on hard, level surface. • Do not use adapters or accessories that are not provided initially. • Lift only on areas of the vehicle as specified by the vehicle manufacturer. • No alterations shall be made to this product.
PAGE 4
SPECIFICATIONS Model Capacity Base Size (L x W) Saddle Diameter Min. Height Max. Height Hydraulic Lift J10500 50 Ton 10-3/4" X 7-5/8" 3-1/8" 9-1/2" 13-7/8" 4-3/8" Saddle Oil Filler Screw Low Pressure High Volume Pump Carry Handle High Pressure Low Volume Pump Release Valve Handle Figure 1 - J10500 Nomenclature MAINTENANCE 3. Fill with oil until just below the rim of the oil filler screw hole. Reinstall the oil filler screw. Important: Use only good grade hydraulic jack oil.
PAGE 5
Replacement Parts for Model J10500 Figure 2 - Model J10500 Replacement Parts Illustration 5
PAGE 6
Replacement Parts List for Models J10500 Item 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 21 22 23 24 25 26 27 28 Part# for model: J10500 244-6-1801-306 248-3-1812-109 324-4-1900-208 601-4-0080-009 248-6-1806-102 * 248-6-1201-108 532-8-0050-024 N/A 238-6-1701-403 248-6-1302-104 518-4-0127-209 * G35-3-1500-208 531-3-0320-002 248-6-1401-106 248-5-1306-106 428-6-1602-209 248-6-1301-102 513-5-0016-018 518-4-00100-108 * 137-4-1500-203 531-3-0190-014 248-6-1403-302 248-6-1306-203 566-4-0070-202 248-3-130
PAGE 7
TROUBLESHOOTING Symptom Possible Causes Corrective Action Jack will not lift load • Release valve not tightly closed • Overload condition • Ensure release valve tightly closed • Remedy overload condition Jack will lift, but not maintain pressure • Release valve not tightly closed • Overload condition • Hydraulic unit malfunction • Ensure release valve tightly closed • Remedy overload condition • Contact BVA Tech.
PAGE 8
Note Page Contact: SFA Companies 10939 N. Pomona Ave. Kansas City, MO 64153, U.S.A. Tel:(888)332-6419 Fax:(816)891-6599 E-Mail:sales@bvahydraulics.com BVA Website: http://www.bvahydraulics.
