P (Value)
Target Antenna Polarization Value for Satellite acquisition
MOD
SQ (Value)
Signal Quality of satellite reception and transmitter status
C_IP (Address)
Controller IP Address
IP
M_IP (Address)
Modem IP Address
S_IP (Address)
Controller Subnet IP Address
GW
G_IP (Address)
Controller Gateway IP Address
OPERATION
FIND
Find Sat
Automatically Find and Lock on to Satellite
STOW
Stow Antenna
Automatically Stow the Antenna
Tx_E
Enable Tx
Enable the Transmitter
Tx_D
Disable Tx
Disable the Transmitter
AZ_C
Calibrate AZ
Calibrate the Azimuth Axis
PL_C
Calibrate PL
Calibrate the Polarization Axis
CP_C
Calibrate CP
Calibrate the Compass
CONFIG
Sat Longitude
Target Satellite Locations Longitudinal Value and Hemisphere
O (Offset)
Target Satellite Offset
Ref SAT Long
Reference Satellite Option
SAT
Ref O (Offset)
Reference Satellite Offset
MDM Freq
Modem Receive Frequency
MDM Sym Rate
Modem Symbol Rate
TR (T-Pol,R-Pol)
Transmit and Receive Polarization
MOD
H (Hem)
Hemisphere of Modem Operation
TP Freq
Transponder Frequency for DVB search
TP Sym Rate
Transponder Symbol Rate for DVB search
TP Code Rate
Transponder FEC (Code) Rate for DVB search
Ref TP Freq
Reference Satellite Transponder Frequency for DVB search
LNB_P
Power supplied to the LNB when searching for target satellite
Ref TP Sym Rate
Reference Satellite Transponder Symbol Rate for DVB search
Ref TP Fec Rate
Reference Satellite Transponder FEC (Code) Rate for DVB search (under
development)
DVB
LNB_P (Ref)
Power supplied to the LNB when searching for reference satellite
O (Value)
Elevation Offset for proper elevation angle readings
W (Value)
Elevation Window Limit for satellite searching
A (Value)
A (Value) – Elevation Adjustment Gap for inclined surfaces
L (UDS)
Up, Down, and Stow Limits enabling (E) or disabling (D) on the Elevation Axis
S (Value)
Slow Speed Settings for Elevation Angle Operation
EL
I (Limits)
Current Limits on EL Axis @ Speed 9 and @ Speed 6
Z (Value)
AZ Pot Zero for converting A/D value for physical determination of AZ zero angle
F (Value)
AZ Pot Factor for converting A/D value to an equivalent azimuth angle
Stow Limit
Stow Limit Enabling (E) or Disabling (D)
W (Value)
Azimuth Search Window Limit for satellite acquisition
S (Value)
Slow Speed Setting for Azimuth Axis.
AZ
I (Limits)
Current Limits on AZ Axis @ Speed 9 and @ Speed 6
Z (Value)
PL Pot Zero for converting A/D value for physical determination of PL zero angle
F (Value)
PL Pot Factor for converting A/D value to an equivalent polarization angle
Skew/Stow Limit
Skew Adjustment and Stow Limit Enabling (E) or Disabling (D)
O (Offset)
Polarization Offset
S (Value)
Slow Speed Setting for Polarization Axis.
PL
I (Limits)
Current Limits on PL Axis @ Speed 9 and @ Speed 6
G (Mode)
GPS Setting (Override, Normal)
GPS Long
GPS Longitudinal Value
GPS Lat
GPS Latitudinal Value
C (Mode)
Compass Setting (Override, Normal)
G&C
H (Value)
Compass Heading if the compass is to be overridden
