6.6.1.6. CP

Displays Compass Status, Compass Heading and the Elevation at which the Compass

is read.

Fig. 19: “CP” Compass Display

(See Compass Configuration section for more detail (G&C))

1 – CP (Compass) Status

V Valid – The compass reading is functioning properly

O Override – the compass has been overridden, and direction entered manually considered

FS Full Search – searches a full 360º search window.

2 – Compass Heading

Compass Heading after Compass has been read.

Approximate Headings: North 354

East 87

South 176

West 265

3 – Compass Elevation Reading

Elevation at which the iNetVu™ 7000 Controller will read the compass. At this Elevation, the

Compass must be level in reference to the ground.

4-Compass Headings

Antenna will rotate 90° to each of the following positions and read the compass at each: 0°, 90°,

180°, -90°, 0° and display the compass headings.

CP: O H :159 CP_EL : 35

V : 0-90-180-270
