6.6.1.7. DVB
Displays the Target Satellite Transponder Frequency, Symbol Rate, and Code Rate in
order to give the DVB Tuner a lock status once pointed towards satellite.
Fig. 20: “SAT” (Satellite) Display
1 – Transponder Number
(There are usually six (6) transponders stored into the controller memory) T0 – T2 are horizontal
Receive, and T3-T5 are vertical receive) The user may overwrite the transponder data with his/her
own.
2 - Target Satellite Transponder L-Band Frequency of the receive signal (MHz)
3 – Target Satellite Transponder Symbol Rate (ksps)
4 – Target Satellite Transponder Code Rate.
5 – Reference Satellite Transponder Number
(There are usually six (6) transponders stored into the controller memory) T0 – T2 are horizontal
Receive, and T3-T5 are vertical receive) The user may overwrite the transponder data with his/her
own.
6 – Reference Satellite Transponder L-Band Frequency of the receive signal (MHz)
This transponder is only used if the Reference Satellite Option is selected in the SAT menu.
7 – Reference Satellite Transponder Symbol Rate (ksps)
8 – Reference Satellite Transponder Code Rate.
9 – Power Supplied to LNB from the 7000 Controller for the Target Satellite
10 – Power Supplied to the LNB from the 7000 Controller for the Reference Satellite.
