6.6.2. OPERATION

Fig. 24: Operation Menu

FIND

(Find Satellite) Performs automatic satellite acquisition.

STOW

Stows the antenna

Tx_E

(Transmitter Enable) Enables the transmitter after locking onto the

designated satellite.

Tx_D

(Transmitter Disable) Disables the transmitter after locking onto the

designated satellite.

AZ_C

(Azimuth Calibration) Performs a complete Azimuth Calibration.

PL_C

(Polarization Calibration) Performs a complete Polarization Calibration.

CP_C

(Compass Check) Tests the Compass’ accuracy and Calibrates the

Compass, should the compass be found to be inaccurate

1 – Find Satellite

Automatically finds and locks onto the satellite signal by communicating with the Satellite Modem

and using the GPS coordinates, the compass heading, and internal parameters of the Satellite

Modem. Typically, it takes approximately 3-5 minutes to find satellite.

If the Antenna is already pointed on the satellite, clicking Find Satellite will re-peak the Antenna

onto the signal.

2 – Stow

Re-centers the antenna and lowers it into the stowed position.

3 –Transmitter Enable

Enables the Transmitter once locked onto satellite.

FIND STOW Tx_E Tx_D

AZ_C PL_C CP_C
