6.6.4.1. E&A&P

1 – Elevation Movement

Allows the user to set the start and stop angle of the elevation axis, as well as set the specific

speed for elevation movement. (E +20:70:7 –implies from angle 20 to 70 at speed 7)

2 – Polarization Movement

Allows the user to set the start and stop angle of the polarization axis, as well as set the specific

speed for polarization movement. (P -60:60:7 –implies from angle -60 to 60 at speed 7)

3 – Azimuth Movement

Allows the user to set the start and stop angle of the azimuth axis, as well as set the specific speed

for azimuth movement. (A -180:180:7 –implies from angle -180 to 180 at speed 7)

4 – Axis Selection and looping option

The first two characters refer to the axis selection (i.e. DD: D).

DD Disable Test for all axes

EL Perform test on the Elevation axis only

AZ Perform test on the Azimuth axis only

PL Perform test on the Polarization axis only

AA Perform tests on all the axes.

The third character refers to the looping intervals between tests (i.e. DD: D).

D Disables looping, test will only be performed once.

1 Infinitely loops with 30-seconds interval between tests.

2 Infinitely loops with 60-seconds interval between tests.

3 Infinitely loops with 90-seconds interval between tests.

4 Infinitely loops with 120-seconds interval between tests.

5 Infinitely loops with 150-seconds interval between tests.

6 Infinitely loops with 180-seconds interval between tests.

7 Infinitely loops with 210-seconds interval between tests.

8 Infinitely loops with 240-seconds interval between tests.

9 Infinitely loops with 270-seconds interval between tests.

5 – Test Selection

Initiates the test on the specified axes according to the specified ranges, and speeds.

E +20:70:7 P-60: 60:7

A-180: 180:7 DD: D TST
