7.2.2.6. Controller Parameters
This sub-section contains data concerning the relevant IP addresses of the iNetVu
TM
7000 Controller.
Fig. 71: Maintenance – Controller Parameters
ID
This ID field is the Controller ID number located on the bottom portion of the controller.
The ID is the last four digits of the controller serial number.
IP
The IP address assigned to the iNetVu
TM
7000 Controller.
GW
The Gateway IP address used by the iNetVu
TM
7000 Controller.
SUB
The Subnet Mask IP Address used by the iNetVu
TM
7000 Controller for PC and modem
connectivity.
COM
This Drop Down Menu allows the user to define the functionality of the serial interface on
the iNetVu
TM
7000 Controller. The following are the options to select from:
 DEBUG -Used for internal debugging purposes.
 MODEM -Used as a communication medium if the specified modem supports serial
interface communication.
 GPS_OUT - Used to pass GPS coordinates from the controller to the modem using the
NEMA standard over the serial communication interface.
