SECURITY CODE Spec. NAME Customer’s Std. Spec. Prepared by Checked by Approved by DATE MITSUBISHI ELECTRIC CORPORATION K.Kurachi R E I.Umezaki V 4-Feb.-2008 HIGH VOLTAGE DIODE MODULE 1. Type Number RM400DG-66S 2. Structure Flat base type (Insulated package, AlSiC base plate) 3. Application & Customer High power converters & Inverters for traction application 4. Outline See Fig. 1 5. Related Specifications Fig.
MITSUBISHI ELECTRIC CORPORATION 6. Maximum Ratings Item Symbol Ratings Unit Repetitive peak reverse voltage VRRM Tj = 25 °C 3300 V Non-repetitive peak reverse voltage VRSM Tj = 25 °C 3300 V Reverse DC voltage VR(DC) Tj = 25 °C 2200 V DC forward current IF Tc = 25 °C 400 A Surge forward current IFSM Tj = 25 °C start, tw = 8.3 ms Half sign wave 3200 A Surge current load integral I2t Tj = 25 °C start, tw = 8.3 ms Half sign wave 42.
MITSUBISHI ELECTRIC CORPORATION 8. Thermal Characteristics Item Symbol Thermal resistance Limits Conditions Junction to case (per 1/2 module) Rth(j-c)R Unit Min. Typ. Max. — — 54.0 K/kW — 48.0 — K/kW (Note 2) Contact thermal resistance Case to fin Conductive grease applied (per 1/2 module) Rth(c-f) Note 2: Thermal conductivity is 1W/mK with a thickness of 100µm. 9. Mechanical Characteristics Item Symbol Conditions Limits Min. Typ. Max.
MITSUBISHI ELECTRIC CORPORATION 11. Test Circuit & Definition of Switching Characteristics LS1 = 500 nH Rg LLOAD LS2 = 100 nH K C = 2 mF V CC DUT: diode CS = 200 uF A Fig. 1 – Switching test circuit Diode part: reverse recovery Qrr = – IF di/dt ∫ t6 VR trr di 0 Irr 10%IF Erec = – ∫ if dt 0 t6 if•vr dt t5 50%Irr dt 90%Irr 0 10%VR 0 t5 t6 Fig.
MITSUBISHI ELECTRIC CORPORATION 12. Performance curves 12-1 Forward characteristics................................................................................................... 6 12-2 Reverse recovery energy characteristics ...................................................................... 7 12-3 Reverse recovery current characteristics...................................................................... 8 12-4 Transient thermal impedance characteristics .................................
MITSUBISHI ELECTRIC CORPORATION 12-1 Forward characteristics 800 700 600 Forward current IF [A] 500 400 300 Tj=125°C 200 Tj=25°C 100 0 0 1 2 3 4 5 6 Forward voltage VFM [V] Forward voltage characteristics (typical) HIGH VOLTAGE DIODE MODULE HVM-2012 (HV-SETSU) PAGE 6 / 11
MITSUBISHI ELECTRIC CORPORATION 12-2 Reverse recovery energy characteristics 0.5 Tj = 125°C, VR = 1650V Ls = 100nH, Inductive load Integration range: 10%VR ~10%IF Reverse recovery energy Erec [J/P] 0.4 0.3 0.2 0.1 0.
MITSUBISHI ELECTRIC CORPORATION 12-3 Reverse recovery current characteristics 1000 Tj = 125°C, VR = 1650V Ls = 100nH, Inductive load Reverse recovery current Irr [A] 800 600 400 200 0 0 100 200 300 400 500 600 700 800 900 Forward current IF [A] Reverse recovery current characteristics (typical) HIGH VOLTAGE DIODE MODULE HVM-2012 (HV-SETSU) PAGE 8 / 11
MITSUBISHI ELECTRIC CORPORATION 12-4 Transient thermal impedance characteristics 1.2 Rth(j-c) = 54 K/kW Normalized transient thermal impedance 1.0 0.8 0.6 0.4 0.2 0.0 0.001 0.01 0.1 1 10 Time [sec.
MITSUBISHI ELECTRIC CORPORATION 12-5 Reverse recovery safe operating area 1000 Tj = 125°C, VR ≤ 2200 V di/dt ≤ 1800A/µs Reverse recovery current Irr [A] 800 600 400 200 0 0 1000 2000 3000 4000 Reverse voltage VR [V] Reverse recovery safe operating area (RRSOA) HIGH VOLTAGE DIODE MODULE HVM-2012 (HV-SETSU) PAGE 10 / 11
MITSUBISHI ELECTRIC CORPORATION Rev. No. − Signature & date K.Kurachi 31-Jan.
