C.T.M.
HS-125 Instruction Booklet TABLE OF CONTENTS INTRODUCTION --------------------------------------------------------1 IMPORTANT PRECAUTIONS ----------------------------------------2 ELECTROMAGNETIC INTERFERENCE AND WARNINGS ----3 IDENTIFICATION OF PARTS ----------------------------------------5 OPERATING YOUR SCOOTER -------------------------------------7 DISASSEMBLING YOUR SCOOTER -------------------------------9 ASSEMBLING YOUR SCOOTER ----------------------------------10 CHARGING THE BATTERIES ---
HS-125 Instruction Booklet INTRODUCTION Thank you and congratulations on purchasing your new C.T.M. Mobility Scooter. It is designed to provide you with transportation indoors and outdoors. Chien Ti Enterprise Co., Ltd. is your manufacturer for the C.T.M. Mobility Scooter. We pride ourselves on providing safe and comfortable products. Our purpose is to give you the complete satisfaction you require. We sincerely hope that you will enjoy your C.T.M. Mobility Scooter.
HS-125 Instruction Booklet IMPORTANT PRECAUTIONS •Only one person at a time can ride a C.T.M. Mobility Scooter. •Maximum load is 115 kgs/253 pounds. •Turn key off before getting on or off. •Always drive carefully and be aware of others using the same area as yourself. •Always use pedestrian crossings where possible. Take extreme care crossing roads. •Do not drive on slopes exceeding 8 degrees, and take extreme care when turning on slopes. •Do not use full power when turning sharp corners.
HS-125 Instruction Booklet ELECTROMAGNETIC INTERFERENCE AND WARNINGS CAUTION: It is very important that you read this information regarding the possible effects of Electromagnetic Interference on your motorized scooter. Powered wheelchairs and motorized scooters may be susceptible to electromagnetic interference (EMI), which is interfering electromagnetic energy (EM) emitted from sources such as radio stations, TV stations, amateur radio (HAM) transmitters, two-way radios, and cellular phones.
HS-125 Instruction Booklet Motorized Scooter Electromagnetic Interference： Because EM energy rapidly becomes more intense as one moves closer to the transmitting antenna (source), the EM fields from hand-held radio wave sources (transceivers) are of special concern. It is possible to unintentionally bring high levels of EM energy very close to the motorized scooter control system while using these devices. This can affect motorized scooter movement and braking.
HS-125 Instruction Booklet IDENTIFICATION OF PARTS Before attempting to drive this scooter on your own, it is important that you familiarize yourself with the controls, and how to operate Flip Up Armrest Thumb Lever Front Basket Rear Compartment Cover Tiller Angle Adjustment Seat Locker Knob One Piece Battery pack Figure 1 - HS-125 Front View Self-diagnostic Warning Light Battery Gauge Main Key Switch Rear Compartment Cover Thumb Lever Horn Button Armrest Width Adjustment Thumbscrews Anti-Tip Whe
HS-125 Instruction Booklet Function Of Parts： TOP CONTROL PANEL •Speed Dial The Rabbit means fast and Turtle is slow. By turning this you control the total speed transferred to the thumb controls. •Self Diagnostic Warning Light Flashing indicates problems with the scooter. See page 13 for more information. •Battery Gauge There are four red LED lights. When all LED are on, the batteries are fully charged. When only two lights are on, the batteries need to be recharged.
HS-125 Instruction Booklet OPERATING YOUR SCOOTER You can make the following adjustments to increase your comfort when driving. •adjust seat height and location •adjust armrest width to comfortable position. •adjust legroom. 1.Before operating your scooter, check the following: •free-wheeling device on D •speed dial is at the turtle picture. 2.Sit on scooter and turn on key. All Battery Gauge LED Lights should be lit. The Self-Diagnostic Warning Light should not be blinking. 3.
HS-125 Instruction Booklet Keep in mind these rules： •Release thumb levers and allow scooter to stop completely before changing from forward to reverse, or reverse to forward. •When turning a corner, swing the front wheels wide, because the back wheels will turn more tightly. •Use the scooter only where it would be safe to walk. •Use low speeds for reverse, downhills, ramps, curbs, or uneven surfaces. Other Operating Information： Hill climbing: You may need to use a higher speed.
HS-125 Instruction Booklet DISASSEMBLING YOUR SCOOTER C.T.M. HS-125's compact design and light weight style fits easily into the trunk or back seat of most cars for transportation. No tools are necessary to disassemble scooter. Remove the seat by loosening the seat Locker Knob (A) and then lift. away. (See Fig. 4) Use the Battery Pack Handle (B) to pull the battery pack up and off from the scooter. (See Fig. 5) (B) (A) Figure 4 Figure 5 Remove the Front Basket (C) and place it off to the side.
HS-125 Instruction Booklet ASSEMBLING YOUR SCOOTER To assemble the scooter, you can repeat the disassembly directions in reverse. Abbreviated directions are given below. Refer to the Figures on pages 9 locate the parts. 1.Adjust the Tiller Angle Adjustment (d) to fix the tiller into its upright position. 2.Place the front basket. 3.Place the battery pack in the battery compartment. 4.Place seat on seat post and tighten the seat locker knob.
HS-125 Instruction Booklet CHARGING THE BATTERIES Your C.T.M. scooter is equipped with two sealed, service free 12V. 12Ah. rechargeable batteries and one 24V. 2A charger. Batteries must be charged before using the scooter for the first time and should be recharged after each day's use. Be sure the scooter is not in free-wheeling mode. 1.Insert battery charger cord into the charger connector on the charger output. Refer to Figure 7. for correct position. Figure 10 2.
HS-125 Instruction Booklet CARE AND MAINTENANCE Cleaning Your Scooter： If your scooter is dirty, use a damp or lightly soapy cloth to wipe it down. Do not use running water to wash or rinse the scooter in order to protect the electrical parts. Polish with an automotive liquid polish. Maintaining Your Scooter： All maintenance and repair of your scooter should be done by an authorized dealer.
HS-125 Instruction Booklet TROUBLESHOOTING Here are some suggestions about solving problems you may have with your scooter. There is a Self-Diagnostic Warning Light on the Control Panel. To check the Self-Diagnostic Warning Light, turn on the key and count the number of blinks on the Warning Light. Number of Flashes Problem Solution 1 Battery needs recharging Recharge the batteries soon. 2 Battery voltage too low to operate scooter M u st r e ch a r g e b e fo r e u sin g.
HS-125 Instruction Booklet Other Problems： During charging, the light on the charger does not change to green: Contact your authorized dealer. Scooter will not move when key is turned on: 1.Check Battery Gauge on the control panel. All the LED Lights should be on. 2.Check Self-Diagnostic Warning Light. It should be steady. If it is flashing, see chart on page 13 for problem identification. 3.Check all electrical connections to be sure they are tight. 4.
HS-125 Instruction Booklet TECHNICAL SPECIFICATIONS Overall Length 39.4" Overall Width 18.5" Overall Height 34.6" Wheels: Front 8" Wheels: Rear 8" Weight w/ Batteries 81.6 lbs Max. Speed 5 mph Weight Capacity 253 lbs 1.4" Ground Clearance 8 degree Grade Climbable Curb Climbing 1.6" Turning Radius 39.6" N/A Suspension Electro-Mechanical Brake Seat Type Padded Foldable Seat Width 16.7" Motor Size 250W 4600 r.p.m Battery (2) 12V. 12Ah Battery Weight 20.5 lbs Travel Range 5.
