Management Module Anomalies This SRN (Software Release Notice) for SPECTRUM 6.0 rev 0 Management Modules identifies anomalies corrected since the lsat release as well as anomalies known to exist in the current release. This information is presented alphabetically by management module. SPMA anomalies affecting various SPECTRUM management modules are listed last.
Ma n ag e me n t M o du l e A no m al i e s 3Com FMS/MSH SPECTRUM Part Name Device SM-3CM1004 10BTi FMS SuperStack II MSH Hubs Firmware 1.32 2.02 4.01 MM Version 6.0 Rev 0 Known Anomalies: Problem 1: If you select the icon in the Alarm view of a Hub3ComMSH, and then open the Application view, a small primary application button appears in the view’s banner. Solution: This problem will be addressed in a future release.
Ma n ag e me n t M o du l e A no m al i e s 3Com LinkSwitch 1100/3300 SPECTRUM Part Name SM-3CM1011 Devices LS1100, LS3300 Firmware 1.06 MM Version 6.0 Rev 0 Known Anomalies: Problem 1: For some firmware releases prior to 2.21, the Interface Device and Device Topology views show interfaces arranged randomly instead of in the proper order of 1.1, 1.2, 1.3, etc. Solution: This was a firmware problem; Firmware 2.21 shows the correct order. The management module functions as designed.
Ma n ag e me n t M o du l e A no m al i e s 3Com NetBuilder II SPECTRUM Part Name Device Firmware SM-3CM1001 3Com N/A NetBuilder MM Version 6.0 Rev 0 Known Anomalies: Problem 1: In the 3Com NetBuilderII’s IP Security Control Table, the columns Control, Packet Default Auth, and Packet System Auth show a value of "|" (pipe). Solution: This problem will be fixed in a future release. Management Module SRN 6.
Ma n ag e me n t M o du l e A no m al i e s 3Com PortSwitch Family SPECTRUM Part Name Device Firmware SM-3CM1008 3Com N/A PortSwitch Family Hub MM Version 6.0 Rev 0 Known Anomalies: Problem 1: In the 3ComRmonExtApp application, the Configuration view’s rfc1516 Extensions, Host Table, and Alarm Event Table print buttons cause SpectroGRAPH to crash. Solution: This problem will be addressed in a future release. Management Module SRN 6.
Ma n ag e me n t M o du l e A no m al i e s AT & T StarLAN10 SmartHUB SPECTRUM Part Name Device Firmware SM-ATT1000 SmartHUB 10.0 MM Version 6.0 Rev 0 Known Anomalies: Problem 1: The SNMP Agent Detail View, accessed from the Application or Performance views, shows pie charts with missing data breakdown fields. Solution: The AT& T StarLAN10 SmartHUB does not fully support MIB I. Some views will not show any information. Management Module SRN 6.
Ma n ag e me n t M o du l e A no m al i e s Bay Centillion 100 SPECTRUM Part Name Device Firmware Version SM-BAN1001 Bay Centillion 2.2.4 100 MM Version 6.0 Rev 0 Known Anomalies: Problem 1: Interface icons in the Device and Device Topology views display port and board labels with an incorrect value of “0.” Solution: This is a firmware problem. Management Module SRN 6.
Ma n ag e me n t M o du l e A no m al i e s CSX200/400 SPECTRUM Part Name Device SM-CSI1077 CSX200/400 SM-CSI1077 CSX5500, CSX7000 Firmware Version 1.03.13 2.01.10 MM Version 6.0 Rev 0 Known Anomalies: Problem 1: The fr1315App’s Frame Relay Data Link Connection Management table for the CSX200 and 400 may incorrectly show the State value as “6.” If you double-click on State, the Data Link Connection Management table view shows “???” for the State value. Solution: This is a firmware problem.
Ma n ag e me n t M o du l e A no m al i e s Cayman GatorStar Repeater/Router SPECTRUM Part Name Device MM Version Firmware SM-CAY1001 RtrCayGBox 3.0.3/2.2.0 RtrCayGMIM 3.0.3/2.2.0 RtrCayGStar 3.0.3/2.2.0 6.
Ma n ag e me n t M o du l e A no m al i e s Cisco Catalyst SPECTRUM Part Name Device Firmware MM Version SM-CAT1000 SwCat 1200 (Catalyst Workgroup Switch) 4.1 6.0 Rev 0 SM-CAT1001 HubCat 1400 (Catalyst Workgroup Concentrator) 1.5 6.0 Rev 0 SM-CAT1002 HubCat 5xxx (Catalyst 5xxx) 2.1 6.0 Rev 0 Known Anomalies: Problem 1: The HubCat5000 and HubCat5500 Interface Translation table shows only Interface Index 1. Solution: This is a firmware problem; the management module functions as designed.
Ma n ag e me n t M o du l e A no m al i e s Problem 4: For SwCat1200 models, double-clicking any interface’s IF Status label displays the Interface Status view with a red-boxed Port Oper Status field. Solution: For switches with firmware versions not supporting the trunking status attribute, Port Oper Status will be red-boxed. Problem 5: In the Device Topology view of the SwCat5505, reconfigured (swapped) boards appear in incorrect numeric order. Solution: The port information is correct.
Ma n ag e me n t M o du l e A no m al i e s Cisco Access Server SPECTRUM Part Name SM-CIS1004 Device AS5x00 (Cisco Access Server) Firmware Version MM Version Experimental 6.0 Rev 0 Version 12.0 Known Anomalies: Problem 1: The AS5x00 T1 port interfaces 4 and 5 show red-boxed attributes in the Interface Configuration view. Interfaces 1-3 and 6-51 show correct values. Solution: This is a firmware problem with the Experimental Version 12.
Ma n ag e me n t M o du l e A no m al i e s Cisco Works Integration Known Anomalies: Problem 1: For any Cisco and Cisco Catalyst models, if Ciscoworks is not correctly installed in your path, then the CiscoView selection on the Cisco model Icon Subviews menu will not work correctly and the following error message will appear: Stop Process Daemon:nmcview -host - No Such File or directory. (This affects Cisco model icons that appear in core application views if Ciscoworks is not installed).
Ma n ag e me n t M o du l e A no m al i e s Cisco Router SPECTRUM Part Name SM-CIS1001 Device Rtr_Cisco (Cisco Router 2) Firmware Version 11.1(8) MM Version 6.0 Rev 0 Rtr_CiscoIGS, 11.2 CGS, AGS, MGS, 2500, 3000, 4000, 7000 SM-CIS1002 Lightstream 10.10 (ATM Support) 11.2(5)/ wa3(2b) 6.0 Rev 0 Known Anomalies: Problem 1: The Cisco 3T MIM is not recognized in hub or MMAC chassis views. Solution: This is a Cisco 3T MIM firmware problem.
Ma n ag e me n t M o du l e A no m al i e s Problem 3: The CiscoPingApp currently supports only the IP and DECnet protocols. The Ping Request Entry Table cannot display multiple protocol address formats using a single table icon. For that reason, non-IP protocols may display their respective addresses incorrectly in the table view but the device receives the address as entered in the “Add Request” window. . Solution: Additional protocols will be supported in a future release of the management module.
Ma n ag e me n t M o du l e A no m al i e s ELS100-24TXG SPECTRUM Part Name SM-CSI1064 Device Firmware Version ELS100-24TXG 2.01.07 MM Version 6.0 Rev 0 Known Anomalies: Problem 1: The Port Information view for the ELS100_TxG incorrectly displays the Port Speed for ports 25 and 26 as “3.” Solution: This is a firmware problem. Problem 2: The Logical Device view cannot be accessed from device icons in some core application windows. Error messages may appear, depending upon the platform.
Ma n ag e me n t M o du l e A no m al i e s EMME/EMM-E6 SPECTRUM Part Name Device Firmware Version MM Version SM-CSI1004 EMME/EMME - 3.08.01 Routing 1.01.02 6.0 Rev 0 SM-CSI1004 EMM-E6 EMM-E6 ADV 6.0 Rev 0 3.22.01 4.01.12 Known Anomalies: Problem 1: The Physical Device view does not show a BRIM inserted into a device. The view only shows a space where a BRIM can be inserted. Solution: This problem will be addressed in a future release of SPECTRUM.
Ma n ag e me n t M o du l e A no m al i e s Problem 3: There is a green or black dot visible in the Physical Device view of the EMM-E6 models. Solution: This problem will be addressed in a future release. Problem 4: If you create an EMME/EMM-E6 model in the Topology view, the Icon Subviews menu for the device will be missing the “Modules” option. This does not occur, however, if you copy the EMME/EMM-E6 into the Location view from the Topology view.
Ma n ag e me n t M o du l e A no m al i e s ESXMIM (Ethernet Switching Bridge) SPECTRUM Part Name Device SM-CSI1039 ESXMIM ESXMIM ADV ESX-1320 ESX-1320 ADV ESX-1380 Firmware 2.30.03 5.10.03 2.30.03 5.10.03 MM Version 6.0 Rev 0 Known Anomalies: Problem 1: The Physical Device view does not show a BRIM inserted into the device; instead, the view only shows a space where a BRIM can be inserted. Solution: This problem will be addressed in a future release. Management Module SRN 6.
Ma n ag e me n t M o du l e A no m al i e s Ethernet Hubs SPECTRUM Part Name Device Firmware Revision MM Version SM-CSI1000 IRBM, IRM-2, 1.07.02 IRM-3 6.0 Rev 0 SM-CSI1000 IRM-3 BP 2.00.01 6.0 Rev 0 SM-CSI1000 MINI-MMAC 2.03.04 6.0 Rev 0 SM-CSI1000 MRXI 22/24 1.11.09 6.0 Rev 0 SM-CSI1000 MRXI-2E 2.03.02 6.0 Rev 0 SM-CSI1000 MRXI-93 SNMP IRM 2.03.02 6.0 Rev 0 Known Anomalies: Problem 1: In the IRBM’s Device Topology view, the Edit menu’s New Model option does not list LAN802.
Ma n ag e me n t M o du l e A no m al i e s FDM SPECTRUM Part Name Device SM-CSI1012 FDMMIM FDMMIM-04 Firmware Version 4.07.06 MM Version 6.0 Rev 0 Known Anomalies: Problem 1: There are no statistical reports being generated for the BdgCSIFDM icon. Solution: Run the reports on the applications for the HubCSIFDDI icon to review the statistical information; the statistical reports function as designed.
Ma n ag e me n t M o du l e A no m al i e s ForeRunner Series of ATM Switches SPECTRUM Part Name Firmware Version Device SM-FOR1000 ASX-100 ASX-200 9A000 ASX-1000 ASX-4000 5.3.1 MM Version 6.0 Rev 0 Corrected Anomalies: 1 Using AutoDiscovery to create an Ethernet LAN and attach the LAN to a ForeSwitch running LANE services works appropriately. Unplaced Information Icons no longer appear in the Topology view of the 802_3 LAN.
Ma n ag e me n t M o du l e A no m al i e s Problem 4: If you try to use the Find view to find the Fore_SONET_App by Model type, the lower portion of the Device view is blank or shows incorrect information. Solution: Do not use the Find view for this purpose; use the conventional methods of accessing the Device view. Problem 5: Attempts to model a ForeSwitch as a GenSNMPDev show the model type as a ForeSystems Workstation, eventually changing to a ForeSys RT router model type.
Ma n ag e me n t M o du l e A no m al i e s Generic SNMP Devices SPECTRUM Part Name SM-CSI1017 Device Firmware Version Generic SNMP N/A MM Version 6.0 Rev 0 Known Anomalies: Problem 1: When some devices are modeled as GnSNMPDev, the Topology view may show the GnSNMPDev models with incorrect name labels. Solution: Generally, this label on the GnSNMPDev model type denotes the name of the manufacturer that initially wrote the firmware. The management module functions as designed.
Ma n ag e me n t M o du l e A no m al i e s Host HP SPECTRUM Part Name SM-GHO1003 Device HP_Host MM Version 6.0 Rev 0 Known Anomalies: Problem 1: For HP_Host, the MIB-II Detail 1 view’s Auth Traps button shows “???” instead of enabled or disabled. The device is not reading the proper value (enabled or disabled) from the MIB. Solution: This is a firmware problem.
Ma n ag e me n t M o du l e A no m al i e s Host Compaq Module SPECTRUM Part Name Device SM-GHO1007 Host Compaq MM Version 6.0 Rev 0 Known Anomalies: Problem 1: The SNMP Agent Detail View is not showing statistical information. Also, the view’s Auth Trap field and the Detail 2 view’s Receive Breakdown and Transmit fields are red-boxed. Changing the Auth Traps from disabled to enabled causes an attribute error message to appear. Solution: This is a firmware problem.
Ma n ag e me n t M o du l e A no m al i e s Host NT Module SPECTRUM Part Name SM-GHO1004 Device MM Version Windows NT 6.0 Rev 0 (pc) Known Anomalies: Problem 1: For the IP2_App application of Host_NT models, the IP Routing view does not display all appropriate fields. Solution: The table is seeing a premature “end of table” being sent from the device. The table then continues to process errors. This is a firmware problem; the management module functions as designed. Management Module SRN 6.
Ma n ag e me n t M o du l e A no m al i e s Kentrox DataSMART SPECTRUM Part Name Device Firmware SM-KEN1001 Kentrox 1.43 DataSMART_680, DataSMART_688 MM Version 6.0 Rev 0 Known Anomalies: Problem 1: Several views for the Kentrox DataSMARTApp contain redboxed attributes. Solution: This problem occurs because the device is not returning any values for these attributes. The management module functions as designed; this is a firmware problem.
Ma n ag e me n t M o du l e A no m al i e s NBR 620, 420, and 220 (Ethernet Bridge Routers) SPECTRUM Part Name SM-CSI1021 Device Firmware Version NBR 2.20.08 NBRBridge/ 3.00.09 Routers (1.11.01 22/ 24E) MM Version 6.0 Rev 0 Known Anomalies: Problem 1: The NBR620 only shows 4 ports in its Device view. Solution: This problem will be addressed in a future release.
Ma n ag e me n t M o du l e A no m al i e s RMON Management Module SPECTRUM Part Name SM-CSI1014 Device Remote Monitoring Firmware Version N/A MM Version 6.0 Rev 0 Known Anomalies: Problem 1: After launching the RMON Suite from the command line of a Cisco Frontier Switch Probe modeled as GnSNMPDev, MAC addresses in the Host Matrix table appear incorrectly.
Ma n ag e me n t M o du l e A no m al i e s RingView for Token Ring Known Anomalies: Problem 1: RingView cannot fully mapconnections within a ring that is configured with multiple hubs or concentrators. This is because the Token Ring device firmware stops mapping MAC addresses to specific ports as soon as it encounters one of the Ring In/Ring Out ports through which the hubs are connected.
Ma n ag e me n t M o du l e A no m al i e s SEHI Hubs SPECTRUM Part Name SM-CSI1020 Device Firmware MM Version Version SEHI 1.10.04 (Stackable Hubs) SEHI-22 SEHI-24 SEHI-32 SEHI-34 6.0 Rev 0 Known Anomalies: Problem 1: When you highlight a port in the Device view and choose Port Frame Size & Protocols from the Icon Subviews menu, the view that displays has Frame Size information only. Solution: Port protocols are not supported by the SEHI device and will, therefore, not show up in the view.
Ma n ag e me n t M o du l e A no m al i e s SFSmartCell Switch (9A656-04, 9A686-04) SPECTRUM Part Name SM-CSI1073 Devices Firmware MM Version Version SmartSwitch 9A656_04 2.04.09 SmartSwitch 9A686_04 6.0 Rev 0 Corrected Anomalies: 1 The 9A656-04 Performance view can now be accessed from the front end panel, and provides appropriate ctmIFPort In Load and Out Load interface status information.
Ma n ag e me n t M o du l e A no m al i e s Problem 3: AutoDiscovery does not resolve the port connection for the 9A656-04. Although you may see a connection between the switches, you will need to resolve the port manually. Solution: To find the port, read the atmInterfaceMyNeighborIpAddress and atmInterfaceMyNeighborIfName from the ATM MIB. (Not all devices fill in atmInterfaceMyNeighborIfName with the port number.
Ma n ag e me n t M o du l e A no m al i e s SmartSwitch 2000 Family SPECTRUM Part Name Devices Firmware Version MM Version SM-CSI1068 2Exx-xx 4.09.08 6.0 Rev 0 SM-CSI1080 2H2x-xxx 2H3x-xxx 4.09.08 6.0 Rev 0 SM-CSI1087 2M46-04R 2M46-04RDC 4.09.08 6.0 Rev 0 Corrected Anomalies: 1 The modeled 2E42-27’s Topology and Model Information views show appropriate information.
Ma n ag e me n t M o du l e A no m al i e s SmartSwitch 8H02-16 SPECTRUM Part Name Firmware Version MM Version SM-CSI1068 8H02-16 1.02.03 (8/ 97) 6.0 Rev 0 SM-CSI1068 8H02-16 ADV 2.02.01 (6/ 97) 6.0 Rev 0 Devices Corrected Anomalies: 1 SS8H traps now generate appropriate events in the Events log. Management Module SRN 6.
Ma n ag e me n t M o du l e A no m al i e s SmartSwitch 6000 Chassis SPECTRUM Part Name Devices Firmware Version MM Version SM-CSI1088 6C105 6C110 4.01.10 6.0 Rev 0 Known Anomalies: Problem 1: Duplicate models will cause erroneous yellow alarm conditions to appear in the 6C105 chassis. The duplicates are overwriting existing models; models are being shifted from correct slot positions and the duplicates are being incorrectly placed into empty chassis slots.
Ma n ag e me n t M o du l e A no m al i e s SmartSwitch 6000 Family SPECTRUM Part Name Devices Firmware MM Version Version SM-CSI1076 6E122-26, 6E128-26, 6E133-25, 6E138-25, 6E123-26, 6E123-50, 6E129-26, 6E132-25 ÿþýüüûüúùø6E133-49, 6E139-25 6E233-49 4.01.10 6.0 Rev 0 SM-CSI1082 6H122-08, 6H122-16, 6H123-50, 6H128-08, 6H129-08, 6H133-37 6H202-24, 6H252-17 4.01.10 1.01.10 1.01.10 6.0 Rev 0 SM-CSI1088 6M146-04 4.01.10 6.
Ma n ag e me n t M o du l e A no m al i e s Problem 3: In the Chassis Device view’s Physical Application Display view for the 6E123-50 and 6H133-37, selecting Port Display Form’s Speed menu choice then selecting the Repeater Port Display Form’s Speed menu choice causes a value of INV (Invalid) to appear for ports. Solution: The Port Display Form speed of 10 mb is correct. The Repeater Port Form speed menu is incorrect and will be removed in a future release.
Ma n ag e me n t M o du l e A no m al i e s SmartSwitch 9000 Dual Backplane SPECTRUM Part Name Devices SM-CSI1098 9C114 9C105 9C106 Firmware Version MM Version 6.0 Rev 0 Known Anomalies: Problem 1: Duplicate models will cause erroneous yellow alarm conditions to appear in any SS9000 chassis. The duplicates are overwriting existing models; models are being shifted from correct slot positions and the duplicates are being incorrectly placed into empty chassis slots.
Ma n ag e me n t M o du l e A no m al i e s SmartSwitch 9000/9500 SPECTRUM Part Name Devices Firmware Version MM Version SM-CSI1030 9E13x-xx 2.06.10 6.0 Rev 0 SM-CSI1031 9F116-01 2.00.06 6.0 Rev 0 SM-CSI1032 9F1xx-xx 2.00.10 6.0 Rev 0 9F2xx-xx SM-CSI1035 9F31x-xx 1.00.30 6.0 Rev 0 9F4xx-xx 1.12.05, 6.0 Rev 0 6.00.15 9F4xxadv SM-CSI1036 9E4xx-xx 1.12.05 6.0 Rev 0 SM-CSI1038 9T122-xx 1.08.07, 6.0 Rev 0 1.02.17 9T125-xx SM-CSI1055 9E106-06 2.10.06 6.
Ma n ag e me n t M o du l e A no m al i e s SPECTRUM Part Name Devices Firmware Version MM Version SM-CSI1098 9G5xx-xx 9H5xx-xx 1.02.09 6.0 Rev 0 SM-CSI109 9H4x 1.12.05, 1.12.00 6.0 Rev 0 9H4xadv 6.00.15 SM-CSI1083 9T425-16 9T428-16 9T427-16 1.12.05 6.0 Rev 0 SM-CSI1092 9M426-02 2.01.02 6.0 Rev 0 Management Module SRN 6.
Ma n ag e me n t M o du l e A no m al i e s Common Anomalies - SmartSwitch 9000/9500 The following affect two or more management modules and the associated devices. Corrected Anomalies: 1 9F426-02 and 9A426-02 device Transparent Bridging Port tables show appropriate MIB-II Interface statistics. In the Chassis Device view of a 9000 device, the ports update when you change the Port Display.
Ma n ag e me n t M o du l e A no m al i e s Problem 4: When modeling a 9A6x6 as a standalone, the Chassis Device view shows CTMifPort icons. The CTMifPort icons should not appear in this view. Solution: This is a firmware problem; upgrade to 3.00.04 or a later firmware version. Problem 5: Error messages may appear when you attempt to save created entries within the Static Bridging application’s Static Bridging Table.
Ma n ag e me n t M o du l e A no m al i e s Problem 7: After modeling a 9E312_12 device, the port interfaces in Device Topology and Device views are not appearing. Twelve interface ports should appear in the views. Also, the Model Information view displays the model state value as "Error." Solution: This firmware problem will be addressed in a future release. Management Module SRN 6.
Ma n ag e me n t M o du l e A no m al i e s SmartSwitch ATM - Zeitnet Switch (2500, 6500, 6A000, 9A100) SPECTRUM Part Name SM-CSI1085 Switches Firmware MM Version Version SmartSwitch 2500 (standalone 2.04.09 ATM; the former Zeitnet ZX-250) SmartSwitch 6A000 (ATM module) SmartSwitch 9A100 (ATM module) SmartSwitch 6500 (ATM backbone) 6.0 Rev 0 Known Anomalies: Problem 1: In the Device Topology view for the ZX_250 model type, the Port Load Status field is blank. Solution: This is a firmware problem.
Ma n ag e me n t M o du l e A no m al i e s Problem 5: The ZX_250 Switch Application Port view shows the Number of Ports field as “7”, while the Port table displays eight rows of port data. Solution: This is a firmware problem. Problem 6: The modeled SS6500 currently does not provide a Chassis Device view, as the SS6500 does not fully support the Container MIB. Solution: This is a firmware problem. Problem 7: Modeled 6Exxx cards (with the ZX-250 SW_Link) do not provide Port Performance view statistics.
Ma n ag e me n t M o du l e A no m al i e s Problem 11: The SS6500’s Zeitnet Systems Extensions view shows redboxed fields. Solution: This is a firmware problem for the SS6500; the field attributes are not supported. Problem 12: The Chassis Device Physical and Backplane views for the SS6500 CSM are incorrectly displaying several blank icons. Solution: This problem will be addressed in a future release. Note: Note: For the 6.
Ma n ag e me n t M o du l e A no m al i e s SmartSwitch ATM Access Module (9A128-01, 9A426-02) SPECTRUM Part Name SM-CSI1059 Devices Firmware MM Version Version SmartSwitch 9A128_01 2.04.09 SmartSwitch 9A426_02 6.0 Rev 0 Corrected Anomalies: 1 The 9A426-02 modules allow access to the Device Topology view now, and show interfaces in other views.
Ma n ag e me n t M o du l e A no m al i e s SmartSwitch FDDI (9F310-02, 9F426-02, 9F426-03) SPECTRUM Part Name SM-CSI1035 Devices Firmware MM Version Version SmartSwitch 9F426_02 1.06.09 SmartSwitch 9F426_03 SmartSwitch 9F310_02 6.0 Rev 0 Known Anomalies: Problem 1: In the Interface Device view of a 9F426-02, three possible interfaces can appear one is the INB interface and the others are FDDI interfaces.
Ma n ag e me n t M o du l e A no m al i e s Gigabit Ethernet SmartSwitch SSX (9G5xx-xx) SPECTRUM Part Name SM-CSI1098 Devices SmartSwitch SSX 9G536_04 Firmware MM Version Version 1.06.09 6.0 Rev 0 Known Anomalies: Problem 1: The 9G5xx-xx boards are incorrectly modeled using the Gen9000 modeltype; the device should be modeled and appear as a 9G5xxxx modeltype. Solution: This firmware problem will be addressed in a future release. Management Module SRN 6.
Ma n ag e me n t M o du l e A no m al i e s SmartSwitch Router (SSR) 250/2000/8000/8600 Known Anomalies: SPECTRUM Part Name Device Firmware Version MM Version SM-CSI1092 SSR2000 3.0.0b.14 6.0 Rev 0 SM-CSI1092 SSR8000/8600 3.1.0.0 3.1.C.5 6.0 Rev 0 SM-CSI1096 SSR-250 3.0.8 6.0 Rev 0 Problem 1: For Generic_SSR_FP models, the Interface Device view’s Console Interface (#3) shows “???” on the Interface Type label. Solution: This firmware problem will be addressed in a future release.
Ma n ag e me n t M o du l e A no m al i e s Problem 4: Serial interfaces for the SSR8600 incorrectly show “10000000” for the ifSpeed. Solution: This firmware problem will be addressed in a future release. Problem 5: When you attempt to run AutoDiscovery using the SmartSwitch router as the seed router, no LANs are created. Solution: This problem will be fixed in future release of SPECTRUM. Problem 6: Fast Ethernet ports are not being created in the Application view.
Ma n ag e me n t M o du l e A no m al i e s SmartSwitch Token Ring MicroLAN Switches (9T122-08, 9T122-24, 9T125-08, 9T125-24) SPECTRUM Part Name SM-CSI1038 Device 9T122_08 9T122_24 9T125_0 (deprecated for 6.0) 9T125_24 Firmware Version 1.03.09 MM Version 6.0 Rev 0 Known Anomalies: Problem 1: In the Physical Device view, the TPIMs (ring-in, ring-out ports) do not display. Solution: The Physical Device view does not fully support the TPIMs. No TPIMs display for any Token Ring device that supports TPIMs.
Ma n ag e me n t M o du l e A no m al i e s SmartSwitch FDDI MicroLAN Switch (9F106-02, 9F116-01, 9F120-08, 9F122-12, 9F125-08, and 9F241-12) SPECTRUM Part Name SM-CSI1095 Device STS16 Token Ring (formerly Olicom TR16) Firmware Version 3.1.0 MM Version 6.0 Rev 0 Known Anomalies: Problem 1: AutoDiscovery does not place the concentrator boards in the container view of the 9F12x-xx or 9F241-12.
Ma n ag e me n t M o du l e A no m al i e s SmartSwitch STS16 Token Ring SPECTRUM Part Name SM-CSI1095 Device STS16 Token Ring (formerly Olicom TR16) Firmware Version 1.06.09 MM Version 6.0 Rev 0 Known Anomalies: Problem 1: Double-clicking on any chassis stack interface in the Chassis Device Topology view causes the interfaces to disappear, and no other information views appear. Solution: Use the Interface Device Topology view to navigate to other information views or complete device connections.
Ma n ag e me n t M o du l e A no m al i e s SynOptics 5000 Hubs SPECTRUM Part Name Device Firmware Version MM Version SM-SYN1003 53xx Enet 55xx TR 59xx FDDI 1.5.1 1.5.1 2.2.6 6.0 Rev 0 SM-SYN1007 SynOptics D5xxx 1.5.0 6.0 Rev 0 Known Anomalies: Problem 1: SynOptics only counts Good Frames when monitoring Ethernet traffic.
Ma n ag e me n t M o du l e A no m al i e s Problem 4: Opening certain SPECTRUM views may cause link error messages to appear in the SpectroGRAPH window. These messages will not affect the operation of SPECTRUM. Solution: This problem will be addressed in a future release. Problem 5: Traps are only generated against the IP address of the first Data Collection Engine (DCE) on an Ethernet or Token Ring Network Management Module (NMM). If contact is lost with the first DCE, the user will not receive traps.
Ma n ag e me n t M o du l e A no m al i e s Problem 10: The HubSyn5DNxx does not appear in the Topology view when modeled by IP. Solution: Exit the Edit mode; the model will then appear in the Topology view. The recommended method is to model the HubSyn5DNxx using the “by Model Type” option. Management Module SRN 6.
Ma n ag e me n t M o du l e A no m al i e s SynOptics Modules Known Anomalies: SPECTRUM Part Name Device Firmware Version MM Version SM-SYN1001 HubSyn3FDDI (SynOptics 3000) 5.1.0 6.0 Rev 0 SM-SYN1002 HubSynEnet28 5.3.1 xx(SynOptics 28xx) 6.0 Rev 0 SM-SYN1004 SynOptics 332xS (Enet Bridge) 6.0 Rev 0 SM-SYN1005 SynOptics 39xx 2.0.48 (FDDI) 6.0 Rev 0 SM-SYN1006 SynOptics 28xxx 2.0.3 6.0 Rev 0 SM-SYN1008 HubSyn27xx (SynOptics 27xx) 5.11 6.
Ma n ag e me n t M o du l e A no m al i e s Problem 2: The 3000 Series chassis has one Ethernet backplane, which can be broken into multiple segments so that more than one Network Management Module (NMM) can exist in the same chassis. HubSynSer3xxx Device views show all the Ethernet modules on the chassis instead of just the modules on the segment. Only the modules on the segment, however, have port information and configuration capability. Solution: This problem will be addressed in a future release.
Ma n ag e me n t M o du l e A no m al i e s TRMM and TRMMIM Token Ring Modules SPECTRUM Part Name Device Firmware Version MM Version SM-CSI1023 TRMM 3.01.06 6.0 Rev 0 SM-CSI1025 TRMMIM TRMMIM-1 3.01.01 6.0 Rev 0 Known Anomalies: Problem 1: The Device view does not show the correct port status nor the board names. Solution: This problem will be addressed in a later firmware release.
Ma n ag e me n t M o du l e A no m al i e s TRMM-2 and TRMM-4 Token Ring Modules SPECTRUM Part Name Device Firmware MM Version SM-CSI1040 TRMM-2 2.00.03 6.0 Rev 0 SM-CSI1041 TRMM-4 2.00.03 6.0 Rev 0 Known Anomalies: Problem 1: If the HubCSITRMM2 is used as a monitor point for the 802.5 LAN, the SystemUpTime is 0, Ring Speed is 0, and no statistical data is calculated. Solution: A model representing the appropriate ring must be chosen; use the HubCSITR model as a monitor point.
Ma n ag e me n t M o du l e A no m al i e s Xylogics Terminal Server II SPECTRUM Part Name Device SM-XYL1001 Annex3 Annex3-UX Firmware MM Version 11.0 6.0 Rev 0 Known Anomalies: Problem 1: For Xyl_CSMIM and Xyl_AnnexII models of devices with firmware versions less than 9.0, the serial number fields in the Device and Application views remain empty. Solution: For versions 9.0 and greater, all views have been updated to support the serial number field. Management Module SRN 6.
Ma n ag e me n t M o du l e A no m al i e s Wellfleet Routers SPECTRUM Part Name Device Firmware MM Version SM-WEL1003 Rtr_Bay_Wflet 14.0 (Wellfleet Router 2) 6.0 Rev 0 SM-WEL1002 Rtr_Wfleet5xx (Wellfleet Series 5 Router) 6.0 Rev 0 5.77 Known Anomalies: Problem 1: For Rtr_Wfleet models of devices with firmware 7.56 and 7.57, the Configuration view’s Console Configuration field is red-boxed. Solution: Firmware 7.80 replaces firmware 7.56 and 7.
Ma n ag e me n t M o du l e A no m al i e s SPMA (SPECTRUM Portable Management Applications) Known Anomalies: Problem 1: Some of the SPMA applications create/use files to store userdefined information. These files are placed in the directory pointed to by the environment variable CTRONDB. By default, the script used to launch SPMA applications sets the CTRONDB variable to: {Install Directory}/SPMA/db directory The retrieved files are owned by the first person to use the SPMA applications.
