20 0 5 C U S TO M E R C O N V E N I E N C E / P E R S O N A L I Z AT I O N G U I D E
C T S TABLE OF CONTENTS DRIVER INFORMATION • Instrument Panel • Lights, Gauges and Indicators • Driver Information Center • DVD Navigation System Controls COMFORT/CONVENIENCE • Daytime Running Lamps • Wipers/Washers • Power Window Controls • HomeLink® Transmitter • Sunroof • Dual Climate Control System SEATS & MIRRORS • Manual Adjustment • Power Adjustment • Heated Front Seats • Electrochromic Day/Night Rearview Mirror With Optional Compass • Power Outside Rearview Mirrors • Curb View Assist Mirror • Me
1 Driver Information INSTRUMENT PANEL 1. Air Outlets 2. Turn Signal/Multifunctional Lever and Cruise Control Switch 3. Configurable Steering Wheel Controls 4. Instrument Panel Cluster 2 3 7 4 5 6 1 8 10 Comfort/ Convenience 9 12 5. Audio Mute Button (Base Radio) or Voice Recognition Button (Navigation System) 6. Audio Volume Knob and Source Button 7. Windshield Wiper Lever 8. Hazard Warning Flasher Button 9. Transmission Shift Lever 14 1 13 10. Climate Control System 11.
C 1 20 2 19 T 4 3 18 17 S 5 6 16 15 14 8 7 13 12 9 11 10 LIGHTS, GAUGES AND INDICATORS 1. 2. 3. 4. 5. 6. 7. Lamps On Reminder Fog Lamp Light Tachometer Cruise Control Light High Beam On Light Speedometer/Odometer Winter Driving Mode Light 8. Malfunction Indicator (Check Engine) Lamp 9. Sport Mode Light 10. Air Bag Readiness Light 11. Safety Belt Reminder Light 12. Fuel Gauge 13. Charging System Light 14. ABS System Warning Light 15. Traction Control Warning Light 16.
IMPORTANT: The instrument cluster is designed to let you know about many important aspects of your vehicle’s operation. Some of the gauges and indicators may differ from the illustration presented. The message center can provide critical information to prevent damage to your vehicle.
C • MPG AVG • MPG INST • GAL FUEL USED • AVG MPH • TIMER • BATTERY VOLTS • ENGINE OIL LIFE 1 • TRANS FLUID LIFE You can view any item at any time (but only one item at a time) by pressing the INFO button. Refer to Section 3 of your Owner Manual for detailed descriptions of the menu items and how to reset them. DVD NAVIGATION SYSTEM CONTROLS If your CTS has the optional DVD Navigation/Audio system, use the following controls to access the vehicle status menu.
Comfort/Convenience DAYTIME RUNNING LAMPS (DRL) Your vehicle’s Daytime Running Lamps (DRL) automatically illuminate the turn signal lights at reduced brightness when: • It is still daylight and the ignition is in the On or Start position. • The headlight lever is in the Off or AUTO position and the headlights are off. • An automatic transmission is not in Park, or the parking brake is not set on a manual transmission.
C POWER WINDOW CONTROLS Express Down All of your vehicle’s windows are equipped with an “Express Down” feature. Press the switch’s down arrow to the second position to activate the express-down feature. Press the up arrow to stop the window. Express Up This feature is on both front power windows. Press the switch’s up arrow to the second position to activate the express-up feature. Press the switch again to stop the window.
3 2 1 4 5 SUNROOF The sunroof control knob is located on the overhead console. The sunshade will always open with the sunroof, but must be closed manually. 1. Half-Open: Turn the control knob clockwise to this position to open the sunroof halfway. 2. Comfort Stop: Turn the control to this position to move the glass panel about three-quarters of the way open. 3. Full Open: Turning the control to this position opens the glass panel all the way. 4.
C T S Seats & Mirrors Front Passenger-Side Air Bag Suppression Your vehicle is equipped with a Passenger Sensing System located in the right front outboard passenger seat. The Passenger Sensing System classifies the occupant sitting in the front passenger seat and communicates the status to the air bag module. The air bag module uses this occupant information to enable or suppress the deployment of the front passenger-side air bag.
HEATED FRONT SEATS (if equipped) The buttons to heat the driver and passenger seats are located at each end of the top row of buttons on the Climate Controls panel. The ignition must be on to heat the seats. When the ignition is turned off, this feature is also turned off. • To set the heat to LO (approximately normal body temperature), press the button twice for the selected seat. Press the button once for the HI setting. Press the button a third time to turn the heat feature off.
C The mirrors can be folded manually inward to prevent damage in car washes or garages. Return the mirrors to their normal positions before driving. The mirrors also are heated to clear fog, snow or ice when the rear defogger is on. Refer to Comfort/Convenience section of this guide. CURB VIEW ASSIST MIRROR (if equipped) If your CTS is equipped with the Memory Seat and Mirrors option, it will also have the Curb View Assist feature.
Audio/Personalization/Communication pages of this Convenience Guide. It is strongly suggested that you spend time to familiarize yourself with the available audio, convenience and personalization features and the procedures to select, activate or program them. Please refer to your Owner Manual and/or the Personalization Instructional Guide provided with this Convenience Guide for detailed descriptions and instructions.
C 3 ONSTAR® (if equipped) OnStar® is a hands-free communications link between the vehicle and the OnStar Center. Your vehicle comes with a specified oneyear service plan that allows you to use some or all of the following services. Services • Contact you and/or dispatch emergency service if an air bag is deployed. • Notify the authorities and track your vehicle if it is reported stolen to OnStar. • Contact and dispatch appropriate help when notified of vehicle breakdown.
Telltale Light 4. The telltale light will be solid green when the system is on and ready to make or receive calls. It will flash when an incoming or outgoing call is in progress. Press the Communication button to answer incoming calls. If the light changes to red to indicate a system malfunction, press the OnStar button to contact an advisor and receive assistance to ensure the system is functioning properly. If an advisor cannot be contacted, take your vehicle to your dealership for assistance.
C T S Powertrain & Maintenance ENGINE Fuel Your CTS is equipped with a 17.5gallon fuel tank. When approximately two gallons are remaining in the tank, a low fuel warning light will illuminate in the Driver Information Center. IMPORTANT The grade of gasoline you use can affect the performance of your vehicle and may even cause damage. Please refer to your Owner Manual for complete information regarding suggested octane ratings for optimum performance.
Winter Driving Mode (automatic transmissions only) The Winter Driving Mode enables the transmission to start the vehicle moving in third gear. Third-gear takeoff reduces torque applied to the rear wheels, which reduces wheelspin during slippery conditions. The vehicle’s acceleration capability will be reduced when this system is activated. Consequently, this feature is not intended for continuous use.
C T S Owner PrivilegesTM To make your ownership experience as satisfying and rewarding as possible, we are proud to provide you with Cadillac’s exceptional Owner Privileges, designed to accommodate you anytime and anywhere.
05CTSGTK A Driver Information Comfort/ Convenience Seats & Mirrors Audio/ Personalization/ Communication Powertrain & Maintenance Owner Privileges
