Dimensions Guide

Café
™
30" Slide-In Front Control Gas
Double Oven with Convection Range
CGS750P4MW2 / CGS750P3MD1 / CGS750P2MS1
Create dinners and desserts at the exact same time - From everyday
gourmet meals to large dinner parties, achieve impressive results with
two independent ovens with a totalcapacity of6.7 cu. ft. for true cooking
flexibility, along with the accurate heat circulation of True European
Convection with Precise Air in the lower oven
An attractive appearance at all times - Every detail of your kitchen is designed
to delight, thanks to a sleek backlit glass touch control panel that visually
disappears when not in use and wakes up when prompted
Enjoy total control in the kitchen and beyond - Control your oven with your
smart device or simply your voice using WiFi Connect
Expansive six-burner cooktop helps you entertain with ease - Entertaining for
large groups is easy with the industry's first six burner, edge-to-edge cooktop
that can accommodate cookware of all sizes and a cast-iron integrated
griddle that provides enough room to perfectly flip crab cakes, arepas and
other crowd favorites
Share favorite creations with your favorite people - Create an unforgettable
dinner, using a 21K tri-ring burner to do everything from searing scallops to
simmering a lemon caper white wine sauce and a 15K power boil burner to
boil water quickly for al dente angel hair pasta
Prepare foods to perfect doneness - Get roasts and meats just right with
a temperature probe that lets you monitor progress without opening the
oven door
Create a look that matches your personal style - Select any combination of
premium finishes and hardwareoptionsto create a stunning look customized
to any owner’s taste
Never scrub racks - Easily remove everything from heavy roasts to delicate
desserts with never scrub racks that stay in the oven during the self-clean cycle
FEATURES & BENEFITS
FEATURES
Configuration Double Oven Range
Cooking System True Convection
Cooking Technology Traditional Upper; Convection Lower
Oven Cleaning Type Self-Clean with Steam Clean Option
Burner - Left Front 21,000 BTU Tri-ring Burner
Burner - Left Rear 5,000 BTU Precise Simmer
Burner - Right Front 15,000 BTU
Burner - Right Rear 12,000 BTU
Burner - Center 9,500 BTU Front / 9,500 BTU Rear
Cooktop Burner Type Sealed
Cooktop Surface Deep Recessed; Stainless Steel
Dishwasher Safe Knobs Ye s
Control Location Front controls
Control Type Backlit; Glass Touch
Valves (Degree of Turn) 270
Oven Control Features
Audible Preheat Signal; Automatic Oven Timer
(Time Bake); Auto Oven Shut-O with Override; Auto
Self Clean; Certified Sabbath Mode; Chef Connect;
Control Lock Capability; Delay Bake Option (Time
Bake); Delay Clean Option; Digipad Numeric Entry;
Electronic Clock and Timer; Front Controls; In-Oven
Broiling; Temperature Probe; Self-Clean Cool Down
Time Display
Oven Cooking Modes Convection Bake; Convection Roast
Cooktop Burner Grate Features Heavy-Cast Edge-to-Edge Grates
Cooktop Burner Grate Material Cast-Iron
Cleaning Time Variable with Delay Clean Option
Self-Clean Oven Door Lock Automatic
Oven Rack Features
1 Self-Clean Flat Oven Rack (Upper); 2 Self-Clean Flat
Oven Racks (Lower); 6 Rack Positions
Fuel Type Natural Gas (factory set)
Ignition System Electronic
Leveling System 4 Leveling Legs
Style Commercial
Oven Interior 2 Oven Interior Lights; Black
Connected Capabilities
Amazon Alexa; The Google Assistant; IFTTT; Nest;
Drop; Innit; DiGiorno
WiFi Connect Built-In
CAPACITY
Total Capacity (cubic feet) 7.0 cu ft
Capacity (Cu. Ft.) 2.7 Upper / 4.3 Lower
ACCESSORIES
Grates Included Center Grate
Grill Optional; Integrated Cast Iron; JXCGRILL1
LP Conversion Kit Included
Trim Kit Optional; JXFILLR1SS
Griddle Included; Integrated Cast Iron
WEIGHTS & DIMENSIONS
Depth with Door Open 43-7/8 in
Approximate Shipping Weight 291 lb
Net Weight 271 lb
Height to Top of Rear Vent Trim 37-3/8 in
Overall Height 37-3/8 in
Height to Cooking Surface (in.) 36-1/4 +/- 1/4
Overall Width 29-7/8 in
Cabinet Width 30 in
Overall Depth 29-1/2 in
Depth Without Handle 26-7/8 in
Oven Interior Dimensions
(W x H x D) (in.)
24 x 9-1/8 x 19-1/8 - Upper
24 x 15 x 20-5/8 - Lower
APPEARANCE
Cooktop Burner Grate Color Matte Black
Oven Door Features Big Clear View Oven Window
Handle Professional Style; Customizable; Consumer Removable
Handle Design Café
CGS750P3MD1
Matte Black with
Brushed Stainless
handles and knobs
ALSO
AVAILABLE IN
ADA
COMPLIANT
CGS750P2MS1
Stainless Steel with
Brushed Stainless
handles and knobs
