2.4 CHANNEL SELECTION
Channel frequencies for 8 channels are programmed using the TSLM Field Programming
Software (FPS). Once programmed, the current operating channel may be selected either by:
1.Utilizing hardware jumpers By strapping connections on the Data Port Connector. There is a
10k ohm pull up resistor on each line (CS0 to CS2) (refer to Table 2-5) or making changes with
the TSLM Field Programming Software:
2.By selecting the channel from the TSLM FPS Offline Diagnostics feature.
Table 2-5 Channel Selection
Channel CS2 CS1 CS0
1 gnd gnd gnd
2 gnd gnd open
3 gnd open gnd
4 gnd open open
5 open gnd gnd
6 open gnd open
7 open open gnd
8 open open open
2.5 TSLM FIELD PROGRAMMING SOFTWARE
The TSLM Field Programming Software provides programming and diagnostics for the
Dataradio TSLM wireless modem. The Field Programming Software allows the user to edit and
program user programmable settings, interactively tune modem and RF parameters, and monitor
diagnostic data from the TSLM.
The PTT Watchdog allows the user to set the maximum transmit time. This is used to protect
against a ‘stuck’ transmitter. The time is selected by a slider bar. The range is 0 to 120 seconds
with a default of 30 seconds.
