1.3 TSLM PART NUMBER BREAKDOWN
The following table shows the breakdown of the TSLM part number.
Table 1-1 TSLM Part Number Breakdown
242-22W0-XYZ
W X Y Z
1 VHF 6 150-174 MHz
7 137-162 MHz
1
1
12.5 kHz
12.5 kHz
0
0
4 UHF 2 403-422 MHz
2 414-430 MHz
5 450-470 MHz
1
1
1
12.5 kHz
12.5 kHz
12.5 kHz
0
1
0
1.4 ACCESSORIES
Table 1-2 TSLM Accessories
Accessory DRL Part Number
Unterminated Power Cable 023-3276-007
DE-15 to DB-9 Power and Data Cable 697-0000-001
Field Programming Kit 250-2200-001
Factory Mutual NI Kit 023-1000-100
Installation Manual for TSLM 001-2200-102 (CD ROM version)
001-2200-101 (Hard Copy version)
DIN Rail Mount 250-4800-406
Switching Power Converter 250-0300-075 (7.5 VDC VOut, 3 Amp)
250-0300-133 (12.5 VDC V Out, 3 Amp)
For information about sales and accessories, contact your sales representative. In the
U.S. phone [phone] or 1-507-833-8819.
1.5 TRANSCEIVER IDENTIFICATION
The transceiver identification number is printed on a label that is affixed to the PC board. The
following information is contained in that number:
Model Revision Manufacturer Warranty
Letter Date Plant Number
22W0 2 A 455 A 12345
Ninth Digit Month Year
of PN
