Electric High Pressure Washer Operating Instructions and Parts Manual PW167600AV For Household Use Only! Carefully read and understand these instructions before operating this pressure washer.
Electric High Pressure Washer Contents Page Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2 Safety and Warning Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2 & 3 Installation Instructions. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3 Setup, Operating and Maintenance Instructions . . . . . . . . . . . . . . . . . . . . . . 4 Troubleshooting Chart . . . . . . . . . . . . . .
PW167600AV Injection hazard. ● Keep clear of nozzle. NEVER direct high pressure spray at any person, animal or self. ● Always wear safety glasses or goggles and protective clothing. Explosion hazard. ● NEVER spray flammable liquids or use pressure washer in areas containing combustible dust, liquids or vapors. Equipment damage. ● ALWAYS turn water supply “ON” before turning pressure washer “ON”. Running pump dry causes serious damage.
Electric High Pressure Washer Setup and Operating Instructions THINGS TO REMEMBER 1. Always check the inlet filter for debris. 2. Always reset the Ground Circuit Interrupter (GFCI) each time the unit is plugged into an outlet. 5. Plug the power cord into a grounded outlet and press the reset button on the GFCI as shown in Figure 12. THIS MUST BE DONE EACH TIME THE UNIT IS PLUGGED INTO AN OUTLET. Reset 3. Slide nozzle to the low pressure position as shown in Figure 14 and apply detergent.
PW167600AV Troubleshooting Chart Symptom Possible Cause(s) Corrective Action(s) Pressure washer does not start up 1. Plug is not well connected or electric socket is faulty 1. Check plug, socket and fuses 2. The main voltage supply is too low 2. Check that the main supply voltage is adequate 3. Thermal safety switch has tripped 3. Switch off the unit and allow the motor to cool down. Leave the lance open. 4. GFCI has tripped 4. Push reset button 1. Water inlet filter is clogged 1.
Electric High Pressure Washer For Replacement Parts or Assistance, Call 1-800-330-0712 Outside the U.S., Puerto Rico, Virgin Islands or Canada, call 1-513-367-4811 then press “0” for assistance Address parts correspondence to: The Campbell Group / Parts Dept. 100 Production Drive Harrison, OH 45030 U.S.A.
PW167600AV Limited Warranty 1. DURATION: From the date of purchase by the original purchaser as follows: Standard Duty Products - One Year, Serious Duty Products - Two Years, Extreme Duty Products - Three Years. 2. WHO GIVES THIS WARRANTY (WARRANTOR): 3. WHO RECEIVES THIS WARRANTY (PURCHASER): The original purchaser (other than for purposes of resale) of the Campbell Campbell Hausfeld / Scott Fetzer Company, 100 Production Drive, Harrison, Ohio, 45030, Telephone: 1-800-330-0712 Hausfeld product. 4.
Electric High Pressure Washer Notes 8
Pulvérisateur de Lavage Électrique Haute Pression Instructions d’Utilisation et Manuel de Pièces de Rechange Pour Usage Domestique Seulement! Lire attentivement et comprendre les instructions suivantes avant d’utiliser ce pulvérisateur de lavage.
Pulvérisateur de Lavage Électrique Haute Pression Contenu Page Spécifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10 Information de Sécurité et Avertissements . . . . . . . . . . . . . . . . . . . . . . 10 - 11 Instructions d’Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11 Instructions de Montage, d’Opération et d’Entretien . . . . . . . . . . . . . . . . . 12 Guide de Dépannage . . . . . . . . . . .
PW167600AV ! Risque d’injection. AVERTISSEMENT ● Se tenir à l’écart de la buse. NE JAMAIS diriger un jet sous haute pression vers une personne, un animal ou soi-même. ● Toujours porter des lunettes de sécurité et des vêtements protecteurs. ! Risque d’explo- AVERTISSEMENT sion. ● NE JAMAIS pulvériser des liquides inflammables, ni utiliser le pulvérisateur de lavage là où il y a de la poussière, liquides ou vapeurs combustibles. ! Dommage à l’équipe- ATTENTION ment.
Pulvérisateur de Lavage Électrique Haute Pression Instructions de Montage et Fonctionnement À SE SOUVENIR 1. Toujours vérifier le filtre d’arrivée pour le débris. clenchement sur DDFT tel qu’indiqué dans la Figure 12. CECI DOIT ÊTRE ACCOMPLI CHAQUE FOIS QUE LE MODÈLE SOIT BRANCHÉ DANS UNE PRISE. IMPORTANT: Le modèle appliquera du détergent seulement lorsque la buse réglable est utilisée et est dans la position de basse pression. Réenclencher Reset BasseLOW Pression PRESSURE 2.
PW167600AV Guide de Dépannage Symptôme Cause(s) Possible(s) Mesure Corrective Le pulvérisateur de lavage ne se démarre pas 1. La fiche n’est pas bien branchée ou la prise de courant est défectueuse 1. Vérifier la fiche, prise et fusibles 2. La source de tension principale est trop basse 2. S’assurer que la source de tension principale soit suffisante 3. La pompe est coincée 3. Tourner le moteur manuellement 4. L’interrupteur de protection thermique est enclenchée 4.
Pulvérisateur de Lavage Électrique Haute Pression Pour des pièces de rechange ou de l’aide, composer 1-800-330-0712 S’il vous plaît fournir l’information suivante: -Numéro de modèle -Numéro de série (si applicable) -Numéro et description de la pièce Correspondance: The Campbell Group / Parts Dept. 100 Production Drive Harrison, OH 45030 U.S.A.
PW167600AV Garantie Limitée 1. DURÉE: À partir de la date d’achat par l’acheteur original - Produits À Service Standard - Un An, Produits À Service Sérieux - Deux Ans, Produits À Service Extrême - Trois Ans. 2. GARANTIE ACCORDÉE PAR (GARANT): Campbell Hausfeld/Scott Fetzer Company, 100 Production Drive, Harrison, Ohio, 45030, Téléphone: 1-800-330-0712 3. BÉNÉFICIAIRE DE CETTE GARANTIE (ACHETEUR): L’acheteur original (sauf en cas de revente) du produit Campbell Hausfeld. 4.
Pulvérisateur de Lavage Électrique Haute Pression Notes 16 Fr
Hidrolavadora Eléctrica Manual de Instrucciones y Lista de Repuestos ¡Sólo para uso doméstico! Lea con cuidado y comprenda estas instrucciones antes de operar esta hidrolavadora.
Hidrolavadora Eléctrica Índice Página Especificaciones. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18 Medidas de seguridad . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18 - 19 Instrucciones para la Instalación . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19 - 20 Instrucciones para conectar, operar y darle mantenimiento . . . . . . . . . 20 - 21 Guía de Diagnóstico de Averías . . . . . . . . . . . . . . . . . . .
PW167600AV ● Si el tomacorrientes disponible en no es adecuado para el cordón eléctrico del producto, un electricista calificado deberá instalar el tomacorrientes necesario. ● Sólo técnicos calificados deben darle mantenimiento a los componentes eléctricos de esta unidad. ● No modifique ninguno de los componentes eléctricos de este producto . ● No use un adaptador para conectar este producto.
Hidrolavadora Eléctrica de la hidrolavadora (Figura 7). 9. Conecte la manguera de succión de 4. Deslice el lado “A” del conector rápido hacia el adaptador y suéltelo. "A" Figura 7 químicos a la parte inferior del mango (Figura 8). Figura 10 PARA CONECTAR EL SISTEMA 1. Cerciórese de que el interruptor esté en OFF (apagado). 2. Conecte la manguera de alta presión y el ensamblaje de la pistola a la unidad. Figura 8 La hidrolavadora está lista para funcionar.
PW167600AV y agua, encienda la unidad y siga los siguientes pasos: Mantenimiento 1. Nunca almacene la unidad a la intemperie o donde se pueda congelar. 2. PERIODOS LARGOS DE ALMACENAMIENTO: Si piensa lamacenar la unidad por más de dos meses, utilice una mezcla de 50% anticongelante --Desconecte las mangueras de alta presión y de jardines. --Vire la unidad de un lado y coloque le interruptor OFF/ON en ON (encendido).
Hidrolavadora Eléctrica Para Ordenar Repuestors, Sírvase Llamer al Concesionario Mas Cerano A Su Domicilio. Puede escribirnos a: The Campbell Group / Parts Dept. 100 Production Drive Harrison, OH 45030 U.S.A. Sírvase suministrarnos la siguiente información: -Número del modelo -Número de serie (de haberlo) -Descripción y número del repuesto según la lista de repuestos 1 3 7 2 4&5 6 No. de Referencia 1 2 3 4 5 6 7 Descripción No. de Pieza Ctd.
PW167600AV Garantía Limitada 1. DURACION: A partir de la fecha de compra por el comprador original tal como se especifica a continuación: Productos Estándard- Un año, Productos Resistentes-Dos años, Productos Robustos- Tres años 2. QUIEN OTORGA ESTA GARANTIA (EL GARANTE: Campbell Hausfeld / The Scott Fetzer Company 100 Production Drive Harrison, Ohio 45030 Telephone: 1-800-330-0712 3.
Hidrolavadora Électrica Notas
